The TP-LINK VIGI NVR2016H-16P is a PoE+ Network Video Recorder designed for users needing robust surveillance solutions. Suitable for homes and businesses, it supports up to 16 video input channels and is capable of high-definition recording.
- Record video in 720p and 1080p resolutions, providing flexibility based on your needs.
- Store up to 10 TB of video data with support for two SATA hard drives.
- Simultaneously playback footage from all 16 channels, enhancing monitoring capabilities.
- Utilize video motion detection to trigger recordings only when activity is detected, conserving storage.
- Connect via Ethernet with data rates of up to 1000 Mbit/s for efficient network performance.
Specifications (1)
- Video input channels: 16-Channel
Other features (1)
- Number of SATA connectors: 2
Technical details (4)
- Producer product family: PoE+ Network Video Recorder
- Producer product name: VIGI NVR2016H-16P
- Net weight: 3.86 kg
- Warranty: 36 month(s)
Performance (1)
- Capacity: Up to 10 TB
Additional specifications (51)
- Number of simultaneously playbacked channels: 16 channels
- Video recording modes: 720p, 1080p
- Maximum resolution: 3840 x 2160 pixels
- Supported resolutions: HDMI Output Resolution: 1 Channel, Resolution: 1280x720/60Hz, 1280x1024/60Hz, 1440x900/60Hz, 1680x1050/60Hz, 1920x1080/60Hz, 3840x2160/30Hz VGA Output Resolution: 1 Channel, Resolution: 1280x720/60Hz, 1280x1024/60Hz, 1440x900/60Hz, 1680x1050/60Hz, 1920x1080/60Hz
- Video motion detection: Yes
- Audio formats supported: G.711 A-law, G.711 μ-law, G.726
- Video formats supported: H.264, H.264+, H.265, H.265+
- Playback modes: Digital zoom, Fast play, Forward, Full screen, Pause, Play, Stop
- Playback controls: Yes
- Maximum frame rate: 30 fps
- Input bandwidth: 80 Mbit/s
- Output bandwidth: 60 Mbit/s
- Recording modes: Manual, Schedule
- Wi-Fi: No
- HDD capacity: 0 GB
- Number of HDDs supported: 2
- Maximum storage capacity: 10 TB
- HDD interface: SATA
- Ethernet LAN (RJ-45) ports: 1
- Power over Ethernet (PoE): Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- Power over Ethernet (PoE) ports quantity: 16
- HDMI ports quantity: 1
- VGA (D-Sub) output ports: 1
- USB 2.0 ports quantity: 2
- eSATA ports quantity: 1
- Internal SATA ports quantity: 2
- eSATA: Yes
- Line-in: Yes
- Audio output: 1
- DC-in jack: Yes
- Networking standards: IEEE 802.3af, IEEE 802.3at
- Supported network protocols: UPnP (Plug and Play), NTP (Network Timing)
- Reset button: Yes
- Product colour: Black
- Certification: CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI
- Power consumption (max): 40 W
- Output current: 2.43 A
- Output voltage: 53.5 V
- Total Power over Ethernet (PoE) budget: 90 W
- Operating temperature (T-T): -10 - 55 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage temperature (T-T): -40 - 70 °C
- Width: 330 mm
- Depth: 285 mm
- Height: 45 mm
- Weight: 1.9 kg
- Package weight: 3.2 kg
- Cables included: AC
- AC adapter included: Yes
- Quick installation guide: Yes
