The TP-LINK TL-SG1008P is a desktop unmanaged switch designed for users needing reliable networking solutions. With 8 Gigabit Ethernet ports and 4 Power over Ethernet (PoE) ports, it efficiently connects and powers devices in a home or small office environment.

  • Provides 8 Gigabit Ethernet ports for fast wired connections, ensuring quick data transfer between devices.
  • Includes 4 PoE ports to simplify installation by powering compatible devices like IP cameras and access points through the same cable.
  • Unmanaged switch design allows for easy plug-and-play setup without complicated configuration, making it user-friendly.
  • Supports a switching capacity of 16 Gbit/s, enabling consistent and efficient data flow for network traffic.
  • Compatible with various cable types (Cat3, Cat4, Cat5, Cat5e), offering flexibility in cabling options.
Specifications (2)
  • Producer product family: Switch
  • Producer product name: TL-SG1008P
Design (1)
  • Form factor: Desktop
Management features (1)
  • Switch type: Unmanaged
Other features (1)
  • Power supply type: External
Ports & interfaces (3)
  • Gigabit Ethernet (copper) ports quantity: 8
  • POE: PoE 802.3 af
  • Predominant port type: 1 Gbps (RJ-45)
Power over Ethernet (PoE) (1)
  • Power over Ethernet (PoE) ports quantity: 4
Technical details (2)
  • Warranty: 60 month(s)
  • Net weight: 0.729 kg
Additional specifications (49)
  • Quality of Service (QoS) support: No
  • Basic switching RJ-45 Ethernet ports quantity: 8
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • Power connector: DC-in jack
  • Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
  • 10G support: No
  • Copper ethernet cabling technology: 1000BASE-T, 100BASE-TX, 10BASE-T
  • Cable types supported: Cat3, Cat4, Cat5, Cat5e
  • Flow control support: Yes
  • Auto MDI/MDI-X: Yes
  • Auto-negotiation: Yes
  • MAC address auto-learning supported: Yes
  • MAC address auto-aging supported: Yes
  • Switching capacity: 16 Gbit/s
  • Forwarding rate: 11.904 Mpps
  • MAC address table: 4000 entries
  • Store-and-forward: Yes
  • Jumbo frames support: Yes
  • Jumbo frames: 16000
  • IGMP snooping: Yes
  • Rack mounting: No
  • Stackable: No
  • Product colour: Grey
  • Housing material: Metal
  • LED indicators: Yes
  • Maximum cable length: 100 m
  • Fanless: Yes
  • Power source: DC/PoE
  • Power supply included: Yes
  • Number of power supply units: 1
  • AC input voltage: 100 - 240 V
  • AC input frequency: 50/60 Hz
  • DC input voltage: 53.5 V
  • Input current: 1.31 A
  • Power consumption (max): 75 W
  • Power over Ethernet (PoE): Yes
  • Total Power over Ethernet (PoE) budget: 64 W
  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 10 - 90%
  • Storage relative humidity (H-H): 5 - 90%
  • Heat dissipation: 225.75 BTU/h
  • Width: 171 mm
  • Depth: 98 mm
  • Height: 27 mm
  • Cables included: AC
  • User guide: Yes
  • Sustainability compliance: Yes
  • Compliance certificates: CE, Federal Communications Commission (FCC), RoHS
Eigenschaften

The TP-LINK TL-SG1008P is a desktop unmanaged switch designed for users needing reliable networking solutions. With 8 Gigabit Ethernet ports and 4 Power over Ethernet (PoE) ports, it efficiently connects and powers devices in a home or small office environment.

  • Provides 8 Gigabit Ethernet ports for fast wired connections, ensuring quick data transfer between devices.
  • Includes 4 PoE ports to simplify installation by powering compatible devices like IP cameras and access points through the same cable.
  • Unmanaged switch design allows for easy plug-and-play setup without complicated configuration, making it user-friendly.
  • Supports a switching capacity of 16 Gbit/s, enabling consistent and efficient data flow for network traffic.
  • Compatible with various cable types (Cat3, Cat4, Cat5, Cat5e), offering flexibility in cabling options.
Specifications (2)
  • Producer product family: Switch
  • Producer product name: TL-SG1008P
Design (1)
  • Form factor: Desktop
Management features (1)
  • Switch type: Unmanaged
Other features (1)
  • Power supply type: External
Ports & interfaces (3)
  • Gigabit Ethernet (copper) ports quantity: 8
  • POE: PoE 802.3 af
  • Predominant port type: 1 Gbps (RJ-45)
Power over Ethernet (PoE) (1)
  • Power over Ethernet (PoE) ports quantity: 4
Technical details (2)
  • Warranty: 60 month(s)
  • Net weight: 0.729 kg
Additional specifications (49)
  • Quality of Service (QoS) support: No
  • Basic switching RJ-45 Ethernet ports quantity: 8
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • Power connector: DC-in jack
  • Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
  • 10G support: No
  • Copper ethernet cabling technology: 1000BASE-T, 100BASE-TX, 10BASE-T
  • Cable types supported: Cat3, Cat4, Cat5, Cat5e
  • Flow control support: Yes
  • Auto MDI/MDI-X: Yes
  • Auto-negotiation: Yes
  • MAC address auto-learning supported: Yes
  • MAC address auto-aging supported: Yes
  • Switching capacity: 16 Gbit/s
  • Forwarding rate: 11.904 Mpps
  • MAC address table: 4000 entries
  • Store-and-forward: Yes
  • Jumbo frames support: Yes
  • Jumbo frames: 16000
  • IGMP snooping: Yes
  • Rack mounting: No
  • Stackable: No
  • Product colour: Grey
  • Housing material: Metal
  • LED indicators: Yes
  • Maximum cable length: 100 m
  • Fanless: Yes
  • Power source: DC/PoE
  • Power supply included: Yes
  • Number of power supply units: 1
  • AC input voltage: 100 - 240 V
  • AC input frequency: 50/60 Hz
  • DC input voltage: 53.5 V
  • Input current: 1.31 A
  • Power consumption (max): 75 W
  • Power over Ethernet (PoE): Yes
  • Total Power over Ethernet (PoE) budget: 64 W
  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 10 - 90%
  • Storage relative humidity (H-H): 5 - 90%
  • Heat dissipation: 225.75 BTU/h
  • Width: 171 mm
  • Depth: 98 mm
  • Height: 27 mm
  • Cables included: AC
  • User guide: Yes
  • Sustainability compliance: Yes
  • Compliance certificates: CE, Federal Communications Commission (FCC), RoHS

TP-LINK Switch TL-SG1008P, Unmanaged, Desktop, Power supply type External

€59,51
€59,51
Steuer enthalten.
