The Aten CS1822 is a 2-Port USB 3.0 4K HDMI KVMP Switch designed for controlling two computers seamlessly. It features multiple connectivity options and supports HDMI video resolution up to 4096 x 2160 pixels.

• Controls up to 2 computers
• Supports HDMI 4K Ultra HD resolution
• Includes 3.5mm headphone and USB A console ports
• Features USB hub with 2 USB 3.2 Gen 1 Type-A ports
• Equipped with LED indicators and hot keys for easy operation

Specifications

• Warranty: 24 month(s)

Technical details

• Net weight: 0.74 kg
• Producer product family: 2-Port USB 3.0 4K HDMI KVMP Switch with Audio Mixer Mode
• Producer product name: CS1822

Additional specifications

• Number of computers controlled: 2
• Keyboard port type: USB
• Mouse port type: USB
• Video port type: HDMI
• HDMI ports quantity: 2
• USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity: 2
• Console ports: 3.5mm headphone, HDMI, USB A
• Console USB ports quantity: 2
• USB hub: Yes
• USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity: 2
• USB connector type: USB Type-A, USB Type-B
• Audio connections: Yes
• Headphone outputs: 3
• Number of microphone inputs: 1
• DC-in jack: Yes
• HD type: 4K Ultra HD
• Maximum resolution: 4096 x 2160 pixels
• Video bandwidth: 60 Hz
• Scan interval: 1,5,99 s
• Product colour: Black
• Housing material: Metal, Plastic
• LED indicators: Yes
• Push button: Yes
• Hot keys: Yes
• Built-in display: No
• Power source: DC
• Input voltage: 5 V
• Power consumption (typical): 1.78 W
• Windows operating systems supported: Yes
• Linux operating systems supported: Yes
• Mac operating systems supported: Yes
• Operating temperature (T-T): 0 - 40 °C
• Storage temperature (T-T): -20 - 60 °C
• Operating relative humidity (H-H): 0 - 80%
• Storage relative humidity (H-H): 0 - 80%
• Width: 210 mm
• Depth: 88 mm
• Height: 55.5 mm
• Weight: 1.39 kg
• Quick installation guide: Yes
• Manual: Yes
• Master (outer) case net weight: 6.95 kg
• Harmonized System (HS) code: 85176200
• Master (outer) case width: 292 mm
• Master (outer) case length: 517 mm
• Master (outer) case height: 194 mm
• Products per master (outer) case: 5 pc(s)
