About
Description
The TP-LINK TL-SF1009P is an unmanaged desktop switch suitable for users needing reliable network connectivity for multiple devices. It offers several fast Ethernet ports and Power over Ethernet capabilities for efficient power management.
- Connect up to 9 devices with 10/100 Mbps Ethernet ports for faster data transfer.
- Utilize 8 PoE+ ports to power compatible devices, eliminating the need for separate power supplies.
- Durable steel casing ensures longevity and stability in various environments.
- Supports automatic features like MDI/MDI-X for easy setup and configuration.
- Compatible with a variety of Ethernet cabling types including Cat5e for flexible installations.
Specifications (3)
- Producer product family: Switch
- Producer product name: TL-SF1009P
- Warranty: 60 month(s)
Design (1)
- Form factor: Desktop
Management features (1)
- Switch type: Unmanaged
Other features (1)
- Power supply type: External
Ports & interfaces (4)
- 10/100 Mbps (RJ-45) ports quantity: 9
- PoE+ ports quantity: 8
- POE: PoE 802.3 af and PoE+ 802.3 at
- Predominant port type: 10/100 Mbps (RJ-45)
Power over Ethernet (PoE) (1)
- Power over Ethernet (PoE) power per port: 30 W
Material (1)
- Case material: Steel
Technical details (1)
- Net weight: 0.662 kg
Additional specifications (49)
- Basic switching RJ-45 Ethernet ports quantity: 9
- Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
- Fast Ethernet (copper) ports quantity: 9
- Power connector: DC-in jack
- Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX
- Cable types supported: Cat3, Cat4, Cat5, Cat5e
- Full duplex: Yes
- Half duplex: Yes
- Flow control support: Yes
- Auto MDI/MDI-X: Yes
- Auto-negotiation: Yes
- MAC address auto-learning supported: Yes
- MAC address auto-aging supported: Yes
- Switching capacity: 1.6 Gbit/s
- Forwarding rate: 1.3392 Mpps
- MAC address table: 2000 entries
- Store-and-forward: Yes
- Rack mounting: No
- Stackable: No
- Product colour: Black
- Housing material: Metal
- LED indicators: Activity, Link, PoE, Power
- Wall mountable: Yes
- Fanless: Yes
- Power source: DC/PoE
- Power supply included: No
- AC input voltage: 220 V
- AC input frequency: 50 Hz
- DC input voltage: 53.5 V
- Input current: 1.31 A
- Power consumption (max): 77.08 W
- Power over Ethernet (PoE): Yes
- Power over Ethernet plus (PoE+) ports quantity: 8
- Total Power over Ethernet (PoE) budget: 65 W
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
- Heat dissipation: 262.84 BTU/h
- Width: 171 mm
- Depth: 98 mm
- Height: 27 mm
- User guide: Yes
- Sustainability compliance: Yes
- Compliance certificates: Federal Communications Commission (FCC), CE, RoHS
- Certification: FCC, CE, RoHS
- Harmonized System (HS) code: 85176990
Description
The TP-LINK TL-SF1009P is an unmanaged desktop switch suitable for users needing reliable network connectivity for multiple devices. It offers several fast Ethernet ports and Power over Ethernet capabilities for efficient power management.
- Connect up to 9 devices with 10/100 Mbps Ethernet ports for faster data transfer.
- Utilize 8 PoE+ ports to power compatible devices, eliminating the need for separate power supplies.
- Durable steel casing ensures longevity and stability in various environments.
- Supports automatic features like MDI/MDI-X for easy setup and configuration.
- Compatible with a variety of Ethernet cabling types including Cat5e for flexible installations.
Specifications (3)
- Producer product family: Switch
- Producer product name: TL-SF1009P
- Warranty: 60 month(s)
Design (1)
- Form factor: Desktop
Management features (1)
- Switch type: Unmanaged
Other features (1)
- Power supply type: External
Ports & interfaces (4)
- 10/100 Mbps (RJ-45) ports quantity: 9
- PoE+ ports quantity: 8
- POE: PoE 802.3 af and PoE+ 802.3 at
- Predominant port type: 10/100 Mbps (RJ-45)
Power over Ethernet (PoE) (1)
- Power over Ethernet (PoE) power per port: 30 W
Material (1)
- Case material: Steel
Technical details (1)
- Net weight: 0.662 kg
Additional specifications (49)
- Basic switching RJ-45 Ethernet ports quantity: 9
- Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
- Fast Ethernet (copper) ports quantity: 9
- Power connector: DC-in jack
- Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX
- Cable types supported: Cat3, Cat4, Cat5, Cat5e
- Full duplex: Yes
- Half duplex: Yes
- Flow control support: Yes
- Auto MDI/MDI-X: Yes
- Auto-negotiation: Yes
- MAC address auto-learning supported: Yes
- MAC address auto-aging supported: Yes
- Switching capacity: 1.6 Gbit/s
- Forwarding rate: 1.3392 Mpps
- MAC address table: 2000 entries
- Store-and-forward: Yes
- Rack mounting: No
- Stackable: No
- Product colour: Black
- Housing material: Metal
- LED indicators: Activity, Link, PoE, Power
- Wall mountable: Yes
- Fanless: Yes
- Power source: DC/PoE
- Power supply included: No
- AC input voltage: 220 V
- AC input frequency: 50 Hz
- DC input voltage: 53.5 V
- Input current: 1.31 A
- Power consumption (max): 77.08 W
- Power over Ethernet (PoE): Yes
- Power over Ethernet plus (PoE+) ports quantity: 8
- Total Power over Ethernet (PoE) budget: 65 W
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 5 - 90%
- Heat dissipation: 262.84 BTU/h
- Width: 171 mm
- Depth: 98 mm
- Height: 27 mm
- User guide: Yes
- Sustainability compliance: Yes
- Compliance certificates: Federal Communications Commission (FCC), CE, RoHS
- Certification: FCC, CE, RoHS
- Harmonized System (HS) code: 85176990
TP-LINK Switch TL-SF1009P, Unmanaged, Desktop, 10/100 Mbps (RJ-45) ports quantity 9
- Regular price
- €55,79
- Sale price
- €55,79
- Regular price
-
Tax included.
Couldn't load pickup availability
