The Gigabyte B860M E GEN5 is a motherboard designed for users looking to build a powerful PC with Intel processors. It supports the latest DDR5 memory and a variety of storage options, making it suitable for gamers and content creators alike.
Key features
| Dimensions | 244 × 35 × 215 mm |
|---|---|
| Number of SATA connectors | 4 |
| Supported hard disk drive interfaces | SATA, M.2 |
| Producer product name | B860M E GEN5 |
| Warranty | 36 month(s) |
| Supported memory types | DDR5 |
| Processor family | Intel |
| Processor socket | LGA1851 |
All specifications (103)
| Internal I/O | |
|---|---|
| Number of SATA connectors | 4 |
| Supported hard disk drive interfaces | SATA, M.2 |
| Technical details | |
| Producer product name | B860M E GEN5 |
| Specifications | |
| Warranty | 36 month(s) |
| Memory | |
| Supported memory types | DDR5 |
| Processor | |
| Processor family | Intel |
| Processor socket | LGA1851 |
| Additional specifications | |
| Processor manufacturer | Intel |
| Compatible processor series | Intel Core Ultra (Series 2) |
| Supported processor sockets | LGA 1851 |
| Number of memory slots | 2 |
| Memory slots type | DIMM |
| Memory channels | Dual-channel |
| ECC сompatibility | ECC & Non-ECC |
| Supported memory clock speeds | 8800,8600,8400,8266,8200,8000,7950,7900,7800,7600,7400,7200,7000,6800,6600,6400,6200,6000,5800,5600 MHz |
| Supported memory clock speed (max) | 8800 MHz |
| Maximum internal memory | 128 GB |
| Unbuffered memory | Yes |
| Maximum internal memory per slot | 64 GB |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, PCI Express 4.0, SATA III |
| Number of HDDs supported | 4 |
| Number of storage drives supported | 6 |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 10 |
| Parallel processing technology support | Not supported |
| Maximum resolution | 4096 x 2160 pixels |
| HDCP | Yes |
| HDCP version | 2.3 |
| DirectX version | 12.0 |
| USB 2.0 connectors | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| Number of SATA III connectors | 4 |
| S/PDIF out connector | Yes |
| Front panel audio connector | Yes |
| Front panel connector | Yes |
| ATX Power connector (24-pin) | Yes |
| CPU fan connector | Yes |
| Number of CPU fan connectors | 2 |
| Number of chassis fan connectors | 1 |
| EPS power connector (8-pin) | Yes |
| Number of EPS power connectors (8-pin) | 1 |
| TPM connector | Yes |
| Serial port headers | 1 |
| Number of water pump connectors | 2 |
| RGB LED pin header | Yes |
| Number of RGB LED pin headers | 2 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| PS/2 ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 2.1 |
| Headphone outputs | 1 |
| Line-in | Yes |
| Microphone in | Yes |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| LAN controller | Realtek RTL8111H |
| Wi-Fi | No |
| Motherboard chipset | Intel B860 |
| Audio chip | Realtek ALC897 |
| Audio output channels | 7.1 channels |
| Product colour | Dark brown |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Component for | PC |
| Motherboard form factor | micro ATX |
| Motherboard chipset family | Intel |
| Cooling type | Passive |
| Power source type | ATX |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| PCI Express x1 (Gen 3.x) slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| Number of M.2 (M) slots | 2 |
| 1st M.2 largest key size | 2280 |
| 1st M.2 highest PCI Express generation | 4.0 |
| 2nd M.2 largest key size | 2280 |
| 2nd M.2 highest PCI Express generation | 4.0 |
| BIOS type | UEFI AMI |
| BIOS memory size | 256 Mbit |
| ACPI version | 5.0 |
| Clear CMOS jumper | Yes |
| Desktop Management Interface (DMI) version | 2.7 |
| System Management BIOS (SMBIOS) version | 2.7 |
| Country of origin | China |
| Products per shipping (inner) case | 1 pc(s) |
| Battery weight | 3 g |
| Lithium weight per battery | 0.07 g |
| Number of battery cells | 1 |
| Battery capacity | 220 mAh |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery type | CR2032 |
| Batteries included | Yes |
| Screws included | Yes |
| Bundled software | Norton®Internet Security (OEM version) |
| Warranty period | 3 year(s) |
| Dimensions & weight | |
| Net weight | 1.00 kg |
| Width | 244 mm |
| Depth | 215 mm |
| Height | 35 mm |
| Weight | 910 g |
Gigabyte B860M E GEN5, Processor family Intel, Processor socket LGA1851, DDR5
- Regular price
- €127,71
- Sale price
- €127,71
- Regular price
-
127,71
102,99
VAT included.Shipping calculated at checkout.
Availability on requestBefore you order and pay, we confirm the item is available, so there are no cancellations or refunds. We reply within 1 business day with the delivery time.See delivery times
Before you order and pay, we confirm the item is available, so there are no cancellations or refunds. We reply within 1 business day with the delivery time.
- Supports Intel Core Ultra processors via LGA1851 socket, enabling high-performance computing.
- Accommodates up to 128 GB of DDR5 memory, allowing for efficient multitasking and demanding applications.
- Features four SATA connectors and M.2 interface for flexible storage configurations with both HDD and SSD options.
- Supports RAID configuration for data redundancy and improved performance, with levels 0, 1, 5, and 10 available.
- Provides a maximum resolution of 4096 x 2160 pixels, ensuring compatibility with high-definition displays.
