The Aten PS/2 VGA 17" LCD Console is designed for users who need a compact solution to control a single computer in a rack-mounted system. This console is suitable for environments where space is limited and low-light visibility is required.

Key features

Dimensions	480 × 44 × 538.3 mm
Producer product name	PS/2 VGA LCD Console
Warranty	24 month(s)
Material	Metal+Plastic
Connector 1	1 x SPHD Female (Yellow)
Connector 2	1 x 3-prong AC Socket
Temperature range (T-T)	0 - 50˚C °C
Other features	Exclusive LED illumination light - designed by ATEN to illuminate the keyboard and touchpad to allow visibility in low-light conditions. Integrated KVM console with 17" or 19” LED-backlit LCD monitor – in a sliding housing with top and bottom clearance for smooth operation in a 1U high system rack. Supports input video resolutions up to 1920 x 1200@60 Hz. LEDs 1 x KVM Console (Dark Green) 1 x LCD (Orange), 1 x NumLock (Green) 1 x CapsLock (Green) 1 x ScrollLock (Green)

All specifications (47)

Specifications
Producer product name	PS/2 VGA LCD Console
Warranty	24 month(s)
Design
Material	Metal+Plastic
Features
Connector 1	1 x SPHD Female (Yellow)
Connector 2	1 x 3-prong AC Socket
Operational conditions
Temperature range (T-T)	0 - 50˚C °C
Technical details
Other features	Exclusive LED illumination light - designed by ATEN to illuminate the keyboard and touchpad to allow visibility in low-light conditions. Integrated KVM console with 17" or 19” LED-backlit LCD monitor – in a sliding housing with top and bottom clearance for smooth operation in a 1U high system rack. Supports input video resolutions up to 1920 x 1200@60 Hz. LEDs 1 x KVM Console (Dark Green) 1 x LCD (Orange), 1 x NumLock (Green) 1 x CapsLock (Green) 1 x ScrollLock (Green)
Additional specifications
Display diagonal	43.2 cm (17")
Display	LCD
Product colour	Black
Operating relative humidity (H-H)	0 - 80%
Maximum resolution	1920 x 1200 pixels
Rack mounting	Yes
Connector type	SPHD
Number of computers controlled	1
LED indicators	Yes
Push button	Yes
Compliance certificates	RoHS
Rack capacity	1U
VGA (D-Sub) ports quantity	1
Keyboard port type	PS/2
Mouse port type	PS/2
Video port type	VGA
DC-in jack	No
Keyboard language	US English
Keyboard layout	QWERTY
Hot keys	Yes
Power consumption (typical)	16 W
Input current	1 A
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Windows operating systems supported	Yes
Mac operating systems supported	Yes
Linux operating systems supported	Yes
Cables included	AC, KVM
Quick installation guide	Yes
Rack mount kit	Yes
Master (outer) case net weight	12 kg
Master (outer) case width	650 mm
Master (outer) case length	604 mm
Master (outer) case height	130 mm
Products per master (outer) case	1 pc(s)
Dimensions & weight
Net weight	12.02 kg
Width	480 mm
Height	44 mm
Depth	538.3 mm
Weight	12 kg

Aten PS/2 VGA LCD Console

Regular price: €695,63
Sale price: €695,63
Regular price

EURVAT 24% excl. VAT?

695,63

560,99

VAT included.Shipping calculated at checkout.

Availability on requestBefore you order and pay, we confirm the item is available, so there are no cancellations or refunds. We reply within 1 business day with the delivery time.See delivery times

Product variants:

The integrated KVM console features a 17" LED-backlit LCD monitor, enabling users to manage their systems efficiently.
Exclusive LED illumination light enhances visibility of the keyboard and touchpad in dark environments.
With support for video resolutions up to 1920 x 1200, this console provides clear visuals for better control and monitoring.
The unit is designed for easy installation in a standard 1U high rack, optimizing space usage.
Hot keys facilitate quick commands, increasing productivity and ease of use.
