The TP-LINK SG2005P-PD Omada is a 5-port managed gigabit smart switch suitable for users needing efficient network management and power over Ethernet capabilities. It features PoE++ input and multiple PoE+ outputs, making it ideal for powering devices like IP cameras and access points.

  • Supports PoE++ to power devices directly through the network cable.
  • Managed functionality allows for detailed network control and configuration.
  • Web-based and cloud management enable easy access and control from anywhere.
  • Quality of Service (QoS) support ensures reliable performance for critical applications.
  • VLAN support allows for enhanced network segmentation and security.
Specifications (3)
  • Producer product family: 5-Port Gigabit Smart Switch with 1-Port PoE++ In and 4-Port PoE+ Out
  • Producer product name: SG2005P-PD Omada
  • Warranty: 60 month(s)
Design (1)
  • Form factor: Desktop
Management features (1)
  • Switch type: Managed L2+
Ports & interfaces (2)
  • POE: PoE++ 802.3 bt
  • Predominant port type: 10/100/1000 Mbps (RJ-45)
Technical details (1)
  • Net weight: 0.51 kg
Additional specifications (61)
  • Switch layer: L2/L2+
  • Quality of Service (QoS) support: Yes
  • Web-based management: Yes
  • Cloud-managed: Yes
  • ARP inspection: Yes
  • MIB support: Y
  • Basic switching RJ-45 Ethernet ports quantity: 4
  • Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
  • 10G Ethernet (copper) ports quantity: 4
  • Networking standards: IEEE 802.11d, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
  • 10G support: Yes
  • Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 100BASE-T
  • Cable types supported: Cat5, Cat5e
  • Port mirroring: Yes
  • Flow control support: Yes
  • Link aggregation: Yes
  • Spanning tree protocol: Yes
  • IPv4 routes: 32
  • IPv6 routes: 32
  • VLAN support: Yes
  • Virtual LAN features: Voice VLAN
  • Number of VLANs: 4000
  • Switching capacity: 10 Gbit/s
  • MAC address table: 8000 entries
  • Jumbo frames support: Yes
  • Jumbo frames: 9
  • Packet forwarding rate (1 Gbps): 7440 pps
  • Packet buffer memory: 4.1 MB
  • DHCP features: DHCP relay, DHCP server
  • Access Control List (ACL): Yes
  • Access Control List (ACL) IPv4 entries: 32
  • IGMP snooping: Yes
  • Security algorithms: 802.1x RADIUS
  • MAC address filtering: Yes
  • IP-MAC-Port binding: Yes
  • Authentication: MAC-based authentication, Port-based authentication
  • Password protection: Yes
  • Multicast support: Yes
  • Multicast MAC address table: 8000 entries
  • IPv4 multicast entries: 511
  • IPv6 multicast entries: 511
  • IPv4 & IPv6 features: Dual stack IPv4/IPv6, IPv4/IPv6 access-control list (ACL), IPv6 tracert
  • Rack mounting: No
  • Stackable: No
  • Product colour: White
  • LED indicators: Yes
  • Power source: DC/PoE
  • Power supply included: Yes
  • Power consumption (typical): 71.5 W
  • Power over Ethernet (PoE): Yes
  • Power over Ethernet (PoE) power per port: 64 W
  • Operating temperature (T-T): -40 - 60 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 10 - 90%
  • Storage relative humidity (H-H): 5 - 90%
  • Heat dissipation: 243.99 BTU/h
  • Width: 170 mm
  • Depth: 100 mm
  • Height: 38.5 mm
  • Sustainability compliance: Yes
  • Compliance certificates: CE, RoHS

TP-LINK SG2005P-PD Omada — 5-Port Gigabit Smart Switch with 1-Port PoE++ In and 4-Port PoE+ Out, Managed L2+, Desktop

€133,91
€133,91
VAT included.
