About

Description

The TP-LINK LS1005 is a 5-port unmanaged desktop network switch, designed for home or small office network setups. It provides essential connectivity for devices like computers and printers, simplifying your networking needs.

  • Connect up to five devices with 10/100 Mbps Ethernet ports for stable speed and efficient data transfer.
  • Auto MDI/MDI-X technology allows for easy setup without needing to configure crossover cables.
  • Supports flow control and store-and-forward switching, ensuring reliable data handling and reducing packet loss.
  • Compact plastic case design fits easily on a desktop, making it suitable for limited space environments.
  • Jumbo frames support enhances performance for large data transfers, with a maximum frame size of 2000 bytes.
Specifications (3)
  • Producer product family: 5-Port 10/100Mbps Desktop Network Switch
  • Producer product name: LS1005
  • Warranty: 36 month(s)
Design (2)
  • Form factor: Desktop
  • Case design: Plastic case
Management features (1)
  • Switch type: Unmanaged
Other features (1)
  • Power supply type: External
Ports & interfaces (3)
  • Ethernet LAN (RJ-45) ports: 5
  • POE: No
  • Predominant port type: 10/100 Mbps (RJ-45)
Technical details (1)
  • Net weight: 0.104 kg
Additional specifications (36)
  • Basic switching RJ-45 Ethernet ports quantity: 5
  • Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
  • Power connector: DC-in jack
  • Networking standards: IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
  • 10G support: No
  • Flow control support: Yes
  • Auto MDI/MDI-X: Yes
  • Auto-negotiation: Yes
  • Switching capacity: 1 Gbit/s
  • Forwarding rate: 0.7 Mpps
  • MAC address table: 2000 entries
  • Store-and-forward: Yes
  • Jumbo frames support: Yes
  • Jumbo frames: 2000
  • Rack mounting: No
  • Product colour: White
  • Housing material: Plastic
  • LED indicators: Activity, Link, Power
  • Wall mountable: No
  • Power source: DC
  • Power supply included: Yes
  • Input current: 0.6 A
  • Input voltage: 5 V
  • Power consumption (max): 1.65 W
  • Power over Ethernet (PoE): No
  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -40 - 60 °C
  • Operating relative humidity (H-H): 10 - 90%
  • Storage relative humidity (H-H): 5 - 90%
  • Heat dissipation: 5.627 BTU/h
  • Width: 83.6 mm
  • Depth: 45.7 mm
  • Height: 22.8 mm
  • Quick start guide: Yes
  • Certification: CE, FCC, RoHS
  • Harmonized System (HS) code: 85176990
Description

The TP-LINK LS1005 is a 5-port unmanaged desktop network switch, designed for home or small office network setups. It provides essential connectivity for devices like computers and printers, simplifying your networking needs.

  • Connect up to five devices with 10/100 Mbps Ethernet ports for stable speed and efficient data transfer.
  • Auto MDI/MDI-X technology allows for easy setup without needing to configure crossover cables.
  • Supports flow control and store-and-forward switching, ensuring reliable data handling and reducing packet loss.
  • Compact plastic case design fits easily on a desktop, making it suitable for limited space environments.
  • Jumbo frames support enhances performance for large data transfers, with a maximum frame size of 2000 bytes.
Specifications (3)
  • Producer product family: 5-Port 10/100Mbps Desktop Network Switch
  • Producer product name: LS1005
  • Warranty: 36 month(s)
Design (2)
  • Form factor: Desktop
  • Case design: Plastic case
Management features (1)
  • Switch type: Unmanaged
Other features (1)
  • Power supply type: External
Ports & interfaces (3)
  • Ethernet LAN (RJ-45) ports: 5
  • POE: No
  • Predominant port type: 10/100 Mbps (RJ-45)
Technical details (1)
  • Net weight: 0.104 kg
Additional specifications (36)
  • Basic switching RJ-45 Ethernet ports quantity: 5
  • Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
  • Power connector: DC-in jack
  • Networking standards: IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
  • 10G support: No
  • Flow control support: Yes
  • Auto MDI/MDI-X: Yes
  • Auto-negotiation: Yes
  • Switching capacity: 1 Gbit/s
  • Forwarding rate: 0.7 Mpps
  • MAC address table: 2000 entries
  • Store-and-forward: Yes
  • Jumbo frames support: Yes
  • Jumbo frames: 2000
  • Rack mounting: No
  • Product colour: White
  • Housing material: Plastic
  • LED indicators: Activity, Link, Power
  • Wall mountable: No
  • Power source: DC
  • Power supply included: Yes
  • Input current: 0.6 A
  • Input voltage: 5 V
  • Power consumption (max): 1.65 W
  • Power over Ethernet (PoE): No
  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -40 - 60 °C
  • Operating relative humidity (H-H): 10 - 90%
  • Storage relative humidity (H-H): 5 - 90%
  • Heat dissipation: 5.627 BTU/h
  • Width: 83.6 mm
  • Depth: 45.7 mm
  • Height: 22.8 mm
  • Quick start guide: Yes
  • Certification: CE, FCC, RoHS
  • Harmonized System (HS) code: 85176990

TP-LINK LS1005 — 5-Port 10/100Mbps Desktop Network Switch, Unmanaged, Power supply type External

€11,15
€11,15
Tax included.
