The ProDVX APPC-10SF is a 10.1-inch Panel PC designed for signage applications, ideal for users who need reliable and high-quality display solutions for various environments. With its robust features and versatility for landscape and portrait placements, it suits businesses seeking effective visual communication tools.

High brightness of 450 cd/m² ensures clear visibility even in well-lit areas.
Wide viewing angles of 160° horizontally and vertically allow for flexible placement and greater audience reach.
Multi-touch touchscreen capability enhances user interaction for applications requiring touch functionality.
Designed for continuous operation, it performs reliably 24/7, catering to demanding signage needs.
VESA mounting compatibility allows easy installation in various settings, ensuring convenience and adaptability.

Display (4)

Placement (L/P): Landscape/Portrait
Viewing angle, horizontal: 160 °
Viewing angle, vertical: 160 °
Contrast ratio (typical): 1000:1

Technical details (8)

Brightness: 450 cd/m²
Producer product name: APPC-10SF
Backlight: Edge-LED backlight
Diagonal: 10.1 "
Display surface: TFT LCD IPS
Net weight: 0.64 kg
Operating hours/days: 24/7
Resolution: 1280 x 800 pixels

Specifications (1)

Warranty: 24 month(s)

Audio (1)

Built-in speaker(s): Yes

Design (4)

Colour of product: Black
Producer product family: Panel PC
VESA mounting: Yes
VESA mounting interfaces: 75 x 75 mm

Other features (1)

Signage product family: Panel PC

Software (3)

Operating system: Android
Operating system installed: Android
Operating system version: 13

Additional specifications (73)

Display diagonal: 25.6 cm (10.1")
Display resolution: 1280 x 800 pixels
Touchscreen: Yes
HD type: HD
LED backlight: Yes
Touch technology: Multi-touch
Native aspect ratio: 16:10
Display brightness: 450 cd/m²
Panel type: IPS
Anti-glare screen: Yes
Processor manufacturer: Rockchip
Processor family: Rockchip
Processor model: RK3568
Processor cores: 4
Processor frequency: 2 GHz
Neural processor unit (NPU): RockChip NPU
AI datatype support on NPU: BFP16, FP16, INT16, Int8
AI software frameworks supported by NPU: Android NN, Caffe, Onnx, Pytorch, TensorFlow, Tflite
NPU performance up to: 1 TOPs
Internal memory: 4 GB
Internal memory type: LPDDR4-SDRAM
Maximum internal memory: 8 GB
Total storage capacity: 16 GB
Storage media: eMMC
Optical drive type: No
Card reader integrated: Yes
Compatible memory cards: SD
Discrete graphics card: No
Discrete graphics card model: Not available
On-board graphics card: Yes
On-board GPU manufacturer: ARM
On-board graphics card family: ARM Mali
On-board graphics card model: Arm Mali-G52
Number of speakers: 2
RMS rated power: 4 W
Built-in microphone: Yes
Audio formats supported: AAC, ASF, MP2, OGG, WAV, WMA
Built-in camera: No
Wi-Fi: No
Wi-Fi ready: Yes
Ethernet LAN: Yes
Ethernet LAN data rates: 1000,100,10 Mbit/s
Bluetooth: No
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
HDMI ports quantity: 1
Audio output: Yes
DC-in jack: Yes
Housing material: ABS synthetics
Product colour: Black
Wall mountable: Yes
Panel mounting interface: 75 x 75 mm
Product type: All-in-One PC
Brand specific technologies: AI-Q Engine, ClearFrame Design, FusionTouch Technology, ProSecure, SLB-Lumi Technology
AC adapter output voltage: 12 V
Power consumption (typical): 23 W
Width (without stand): 240.9 mm
Depth (without stand): 24.4 mm
Height (without stand): 159.7 mm
Weight (without stand): 600 g
Weight: 600 g
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -10 - 55 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 10 - 90%
Compliance certificates: Federal Communications Commission (FCC), CE, RoHS, REACH, UKCA
AC adapter output current: 2 A
Mean time between failures (MTBF): 50000 h
Video formats supported: H.264, MP4, MPEG2, MPEG4, MPG
Battery type: CR1220 Lithium metal, non rechargeable
Mini HDMI ports quantity: 1
Backlight type: Edge LED
