New Genuine Bosch 061124A000 GBH 3-28 DFR Professional Rotary Hammer with SDS plus

Rotary Hammer with SDS plus

Technical data

Performance data

Impact rate at rated speed 0 - 4.000 bpm

Rated speed 0 - 900 rpm

Additional data

Rated input power 800 W

Impact energy (according to EPTA 05/2016) 3.1 J

Voltage, electrical 230 V

Weight 3.6 kg

Tool holder SDS plus

Drilling range

Drilling dia. concrete, hammer drill bits 4 - 28 mm

Opt. appl. range concrete, hammer drill bits 12 - 18 mm

Max. drilling diameter in metal 13 mm

Max. drilling diameter in wood 30 mm

Total vibration values (Hammer drilling in concrete)

Vibration emission value ah 11.8 m/s²

Uncertainty K 1.5 m/s²

Total vibration values (Chiselling in concrete)

Vibration emission value ah 10 m/s²

Uncertainty K 1.5 m/s²

Hammer drilling in concrete

Vibration emission value ah 11.8 m/s²

Uncertainty K 1.5 m/s²

Chiselling in concrete

Vibration emission value ah 10 m/s²

Uncertainty K 1.5 m/s²

GBH 3-28 DFR Professional: Further information

Product Highlights

The GBH 3-28 DFR Professional is the most versatile tool in Bosch's SDS plus corded rotary hammer category. Its compact housing enables multiple applications in narrow and tight workspaces. Designed for convenience, its L-shaped design provides a balanced weight distribution, while its Vibration Control allows effortless continuous work. It also features a high power-to-weight ratio, with an 800 W motor and a tool weight of only 3.6 kg.

Top performance with 20% less vibration

High drilling rate and 20% higher chiselling power than other rotary hammers in its class
20% less vibration than other hammers in its class for more comfortable working due to Bosch Vibration Control
Quick change chuck for fast changes between drilling with impact in concrete and drilling without impact in wood and metal

Brand: Bosch

SKU: 061124A000

EAN: 3165140471176
