Description

The D-Link DEM-432XT is a transceiver designed for high-speed networking. It is suitable for users needing reliable data transfer over long distances in fiber optic networks.

  • Supports a maximum transfer distance of up to 10,000 m, ideal for extensive networking setups.
  • Operates at a wavelength of 1310 nm, ensuring efficient data transmission.
  • Compatible with single-mode fiber cables, facilitating seamless integration into existing systems.
  • Designed to work within a wide temperature range from 0 to 70 °C, making it adaptable to various environments.
  • Provides data transfer rates of up to 10,000 Mbit/s, enabling fast and efficient communication in networks.
Specifications (1)
  • Producer product name: DEM-432XT
Performance (11)
  • Maximum transfer distance: 10000 m
  • Wavelength: 1310 nm
  • Cable type: Single-mode
  • Certification: CE, FCC, VCCI
  • Data transfer rate (max): 10000 Mbit/s
  • Fiber cable diameters supported: 9/125 µm
  • Networking standards: IEEE 802.3ae
  • Rx power (max): 0.5 dBmW
  • Rx power (min): -12.6 dBmW
  • Tx power (max): 0.5 dBmW
  • Tx power (min): -8.5 dBmW
Certificates (1)
  • Safety: UL, TUV, CDRH
Features (1)
  • RoHS compliance: Yes
Networking (2)
  • Fiber optic connector: LC
  • Interface type: SFP+
Operational conditions (4)
  • Operating relative humidity (H-H): 5 - 85 %
  • Operating temperature (T-T): 0 - 70 °C
  • Storage relative humidity (H-H): 5 - 95 %
  • Storage temperature (T-T): -40 - 85 °C
Power (2)
  • Output current: 300 A
  • Output voltage: 3.3 V
Technical details (3)
  • Net weight: 19.5 kg
  • Type: Transceiver
  • Warranty: 24 month(s)
Weight & dimensions (4)
  • Depth: 1.19 cm
  • Height: 5.65 cm
  • Weight: 19.5 g
  • Width: 1.48 cm
Additional specifications (21)
  • SFP transceiver type: Fiber optic
  • Maximum data transfer rate: 10000 Mbit/s
  • Single-mode fiber (SMF) supported: Yes
  • Multi-mode fiber (MMF) supported: No
  • Fiber cable diameters supported (core/cladding): 9/125 µm
  • SFP transceiver standard: LR
  • Link budget: 10.1 dB
  • Fiber ethernet cabling technology: 10GBASE
  • Duplex system: Full
  • Product colour: Gold, Metallic
  • Hot-Plug support: Yes
  • Mean time between failures (MTBF): 4650000 h
  • Maximum voltage: 3.3 V
  • Maximum current: 300 A
  • Compliance certificates: RoHS
  • Shipping (inner) case length: 36 cm
  • Shipping (inner) case width: 26 cm
  • Shipping (inner) case height: 31 cm
  • Shipping (inner) case net weight: 3.2 kg
  • Products per shipping (inner) case: 50 pc(s)
  • Harmonized System (HS) code: 85369010
Description

The D-Link DEM-432XT is a transceiver designed for high-speed networking. It is suitable for users needing reliable data transfer over long distances in fiber optic networks.

  • Supports a maximum transfer distance of up to 10,000 m, ideal for extensive networking setups.
  • Operates at a wavelength of 1310 nm, ensuring efficient data transmission.
  • Compatible with single-mode fiber cables, facilitating seamless integration into existing systems.
  • Designed to work within a wide temperature range from 0 to 70 °C, making it adaptable to various environments.
  • Provides data transfer rates of up to 10,000 Mbit/s, enabling fast and efficient communication in networks.
Specifications (1)
  • Producer product name: DEM-432XT
Performance (11)
  • Maximum transfer distance: 10000 m
  • Wavelength: 1310 nm
  • Cable type: Single-mode
  • Certification: CE, FCC, VCCI
  • Data transfer rate (max): 10000 Mbit/s
  • Fiber cable diameters supported: 9/125 µm
  • Networking standards: IEEE 802.3ae
  • Rx power (max): 0.5 dBmW
  • Rx power (min): -12.6 dBmW
  • Tx power (max): 0.5 dBmW
  • Tx power (min): -8.5 dBmW
Certificates (1)
  • Safety: UL, TUV, CDRH
Features (1)
  • RoHS compliance: Yes
Networking (2)
  • Fiber optic connector: LC
  • Interface type: SFP+
Operational conditions (4)
  • Operating relative humidity (H-H): 5 - 85 %
  • Operating temperature (T-T): 0 - 70 °C
  • Storage relative humidity (H-H): 5 - 95 %
  • Storage temperature (T-T): -40 - 85 °C
Power (2)
  • Output current: 300 A
  • Output voltage: 3.3 V
Technical details (3)
  • Net weight: 19.5 kg
  • Type: Transceiver
  • Warranty: 24 month(s)
Weight & dimensions (4)
  • Depth: 1.19 cm
  • Height: 5.65 cm
  • Weight: 19.5 g
  • Width: 1.48 cm
Additional specifications (21)
  • SFP transceiver type: Fiber optic
  • Maximum data transfer rate: 10000 Mbit/s
  • Single-mode fiber (SMF) supported: Yes
  • Multi-mode fiber (MMF) supported: No
  • Fiber cable diameters supported (core/cladding): 9/125 µm
  • SFP transceiver standard: LR
  • Link budget: 10.1 dB
  • Fiber ethernet cabling technology: 10GBASE
  • Duplex system: Full
  • Product colour: Gold, Metallic
  • Hot-Plug support: Yes
  • Mean time between failures (MTBF): 4650000 h
  • Maximum voltage: 3.3 V
  • Maximum current: 300 A
  • Compliance certificates: RoHS
  • Shipping (inner) case length: 36 cm
  • Shipping (inner) case width: 26 cm
  • Shipping (inner) case height: 31 cm
  • Shipping (inner) case net weight: 3.2 kg
  • Products per shipping (inner) case: 50 pc(s)
  • Harmonized System (HS) code: 85369010

D-Link DEM-432XT, Wavelength 1310 nm, Maximum transfer distance 10000 m

€338,51
€338,51
Tax included.
