About
Description
The Aten VS291-A7-G is a 2-port video switch designed for users who need to manage multiple VGA sources. Ideal for home or office setups, it allows seamless switching between devices to a single display or projector.
- Supports up to 1920 x 1440 resolution for clear image quality.
- Features two VGA input ports and one output port for flexible device connections.
- Compact design and lightweight build make it easy to integrate into any workspace.
- DC-in jack enables reliable power supply, ensuring consistent performance.
- LED indicators provide easy status visibility for active sources.
Specifications (1)
- Warranty: 24 month(s)
Ports & interfaces (1)
- Video port type: 2 x VGA
Technical details (3)
- Net weight: 0.15 kg
- Producer product family: Video switch - 2 ports
- Producer product name: VS291-A7-G
Additional specifications (31)
- VGA (D-Sub) ports quantity: 3
- VGA (D-Sub) input ports: 2
- VGA (D-Sub) output ports: 1
- DC-in jack: Yes
- Material: Metal, Plastic
- Product colour: Silver
- Maximum refresh rate: 60 Hz
- Maximum operating distance: 10 m
- Supported graphics resolutions: 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1600 x 1200 (UXGA), 1920 x 1440
- LED indicators: Yes
- Bandwidth: 150 MHz
- Maximum resolution: 1920 x 1440 pixels
- Input impedance: 75 Ω
- Output impedance: 75 Ω
- Power consumption (typical): 0.82 W
- Width: 65.2 mm
- Depth: 120 mm
- Height: 44 mm
- Weight: 220 g
- Quantity per pack: 1 pc(s)
- AC adapter included: Yes
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
- Storage relative humidity (H-H): 0 - 80%
- Harmonized System (HS) code: 85176990
- Master (outer) case width: 315 mm
- Master (outer) case length: 490 mm
- Master (outer) case height: 338 mm
- Products per master (outer) case: 20 pc(s)
- Master (outer) case net weight: 4.4 kg
Description
The Aten VS291-A7-G is a 2-port video switch designed for users who need to manage multiple VGA sources. Ideal for home or office setups, it allows seamless switching between devices to a single display or projector.
- Supports up to 1920 x 1440 resolution for clear image quality.
- Features two VGA input ports and one output port for flexible device connections.
- Compact design and lightweight build make it easy to integrate into any workspace.
- DC-in jack enables reliable power supply, ensuring consistent performance.
- LED indicators provide easy status visibility for active sources.
Specifications (1)
- Warranty: 24 month(s)
Ports & interfaces (1)
- Video port type: 2 x VGA
Technical details (3)
- Net weight: 0.15 kg
- Producer product family: Video switch - 2 ports
- Producer product name: VS291-A7-G
Additional specifications (31)
- VGA (D-Sub) ports quantity: 3
- VGA (D-Sub) input ports: 2
- VGA (D-Sub) output ports: 1
- DC-in jack: Yes
- Material: Metal, Plastic
- Product colour: Silver
- Maximum refresh rate: 60 Hz
- Maximum operating distance: 10 m
- Supported graphics resolutions: 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1600 x 1200 (UXGA), 1920 x 1440
- LED indicators: Yes
- Bandwidth: 150 MHz
- Maximum resolution: 1920 x 1440 pixels
- Input impedance: 75 Ω
- Output impedance: 75 Ω
- Power consumption (typical): 0.82 W
- Width: 65.2 mm
- Depth: 120 mm
- Height: 44 mm
- Weight: 220 g
- Quantity per pack: 1 pc(s)
- AC adapter included: Yes
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
- Storage relative humidity (H-H): 0 - 80%
- Harmonized System (HS) code: 85176990
- Master (outer) case width: 315 mm
- Master (outer) case length: 490 mm
- Master (outer) case height: 338 mm
- Products per master (outer) case: 20 pc(s)
- Master (outer) case net weight: 4.4 kg
Aten VS291-A7-G — Video switch - 2 ports, 2 x VGA
- Regular price
- €44,63
- Sale price
- €44,63
- Regular price
-
Tax included.
Couldn't load pickup availability
