The Aten 3 Phase 0U PDU Outlet is designed for users needing reliable power distribution in a data center or server rack environment. With multiple outlets and advanced monitoring features, it provides efficient management of power across equipment.

  • Supports a total of 30 AC outlets, including 6 C19 and 24 C13 types, allowing flexible connection for various devices.
  • Features an LCD display for real-time monitoring of current, power, and voltage metrics.
  • Includes dual Ethernet ports and a USB port, facilitating easy connectivity and management through network protocols.
  • Daisy chaining capability enables easy expansion of power distribution across multiple units.
  • Password protection and security algorithms ensure safe remote access and management of the PDU.
Specifications (1)
  • Warranty: 24 month(s)
Technical details (3)
  • Net weight: 8.43 kg
  • Producer product family: 3 Phase 0U PDU Outlet Metered and Switched 32A 6xC19 24xC13 400V/230V Star
  • Producer product name: PG98330G
Additional specifications (45)
  • PDU types: Metered, Switched
  • Type: Three-phase
  • Rack mounting: Yes
  • Rack capacity: 0U
  • Product colour: Black
  • Display: LCD
  • AC outlets quantity: 30 AC outlet(s)
  • Power plug: IEC309
  • AC outlet types: C13 coupler, C19 coupler
  • Serial ports quantity: 2
  • Ethernet LAN (RJ-45) ports: 2
  • USB ports quantity: 1
  • Daisy chain: Yes
  • Reset button: Yes
  • Cable length: 3 m
  • Security algorithms: SMTP-AUTH, TLS
  • Password protection: Yes
  • Monitoring: Current, Power, Voltage
  • Supported network protocols: /IP, UDP, HTTP, HTTPS, SSL, DHCP, SMTP, ARP, NTP, DNS, Auto Sense, Ping, SNMP V1&V2&V3, Telnet, Modbus (over TCP/IP), Wi-Fi, 802.11 a/b/g/n, IPv6, SMS
  • Firmware upgradeable: Yes
  • Firmware upgradeable via: Network
  • Nominal input voltage: 230 - 400 V
  • AC input frequency: 50 - 60 Hz
  • Maximum current: 32 A
  • Nominal output voltage: 230 V
  • Load capacity: 22170 VA
  • Circuit breaker: Yes
  • Compliance certificates: CE
  • Certification: EMC
  • Sustainability compliance: Yes
  • Operating temperature (T-T): 0 - 60 °C
  • Storage temperature (T-T): -20 - 60 °C
  • Operating relative humidity (H-H): 0 - 80%
  • Width: 56 mm
  • Depth: 1790 mm
  • Height: 68 mm
  • Weight: 8.43 kg
  • Manual: Yes
  • Rack mount kit: Yes
  • Country of origin: Taiwan
  • Master (outer) case net weight: 11.2 kg
  • Master (outer) case width: 229 mm
  • Master (outer) case length: 1945 mm
  • Master (outer) case height: 179 mm
  • Master (outer) case volume: 79853.5 cm³

Aten PG98330G — 3 Phase 0U PDU Outlet Metered and Switched 32A 6xC19 24xC13 400V/230V Star

€2.103,03
€2.103,03
VAT included.
