About

Description

The Aten CS1953 is a 3-Port USB-C DisplayPort Hybrid KVMP™ Switch designed for users who need to control multiple computers with ease. Ideal for professionals who work across different devices, this switch allows seamless switching between up to three computers while sharing a single keyboard, mouse, and monitor setup.

  • Supports 4K Ultra HD resolution at 4096 x 2160 pixels for clear visual output.
  • Includes multiple USB ports for connecting peripherals, enhancing your workspace efficiency.
  • Audio connections with headphone outputs and microphone input for versatile multimedia use.
  • Features LED indicators and push button for easy operation and status visibility.
  • Hot key functionality allows quick and convenient switching between connected computers.
Specifications (1)
  • Warranty: 24 month(s)
Technical details (3)
  • Net weight: 0.5 kg
  • Producer product family: 3-Port USB-C DisplayPort Hybrid KVMP™ Switch with power adapter
  • Producer product name: CS1953
Additional specifications (45)
  • Number of computers controlled: 3
  • Keyboard port type: USB
  • Mouse port type: USB
  • Video port type: DisplayPort
  • DisplayPorts quantity: 2
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity: 3
  • Console ports: 3.5mm headphone, 3.5mm mic, DisplayPort, USB A
  • Console USB ports quantity: 2
  • USB hub: Yes
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity: 2
  • USB connector type: USB Type-A, USB Type-B
  • Audio connections: Yes
  • Headphone outputs: 4
  • Number of microphone inputs: 1
  • DC-in jack: Yes
  • HD type: 4K Ultra HD
  • Maximum resolution: 4096 x 2160 pixels
  • Video bandwidth: 60 Hz
  • Scan interval: 1,5,99 s
  • Product colour: Black
  • Housing material: Metal, Plastic
  • LED indicators: Yes
  • Push button: Yes
  • Hot keys: Yes
  • Built-in display: No
  • Power source: DC
  • Input voltage: 12 V
  • Power consumption (typical): 5.78 W
  • Windows operating systems supported: Yes
  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -20 - 60 °C
  • Operating relative humidity (H-H): 0 - 80%
  • Storage relative humidity (H-H): 0 - 80%
  • Width: 206.3 mm
  • Depth: 75.4 mm
  • Height: 44 mm
  • Weight: 960 g
  • Quick installation guide: Yes
  • Manual: Yes
  • Master (outer) case net weight: 4.8 kg
  • Harmonized System (HS) code: 85176200
  • Master (outer) case width: 232 mm
  • Master (outer) case length: 500 mm
  • Master (outer) case height: 283 mm
  • Products per master (outer) case: 5 pc(s)
Description

The Aten CS1953 is a 3-Port USB-C DisplayPort Hybrid KVMP™ Switch designed for users who need to control multiple computers with ease. Ideal for professionals who work across different devices, this switch allows seamless switching between up to three computers while sharing a single keyboard, mouse, and monitor setup.

  • Supports 4K Ultra HD resolution at 4096 x 2160 pixels for clear visual output.
  • Includes multiple USB ports for connecting peripherals, enhancing your workspace efficiency.
  • Audio connections with headphone outputs and microphone input for versatile multimedia use.
  • Features LED indicators and push button for easy operation and status visibility.
  • Hot key functionality allows quick and convenient switching between connected computers.
Specifications (1)
  • Warranty: 24 month(s)
Technical details (3)
  • Net weight: 0.5 kg
  • Producer product family: 3-Port USB-C DisplayPort Hybrid KVMP™ Switch with power adapter
  • Producer product name: CS1953
Additional specifications (45)
  • Number of computers controlled: 3
  • Keyboard port type: USB
  • Mouse port type: USB
  • Video port type: DisplayPort
  • DisplayPorts quantity: 2
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity: 3
  • Console ports: 3.5mm headphone, 3.5mm mic, DisplayPort, USB A
  • Console USB ports quantity: 2
  • USB hub: Yes
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity: 2
  • USB connector type: USB Type-A, USB Type-B
  • Audio connections: Yes
  • Headphone outputs: 4
  • Number of microphone inputs: 1
  • DC-in jack: Yes
  • HD type: 4K Ultra HD
  • Maximum resolution: 4096 x 2160 pixels
  • Video bandwidth: 60 Hz
  • Scan interval: 1,5,99 s
  • Product colour: Black
  • Housing material: Metal, Plastic
  • LED indicators: Yes
  • Push button: Yes
  • Hot keys: Yes
  • Built-in display: No
  • Power source: DC
  • Input voltage: 12 V
  • Power consumption (typical): 5.78 W
  • Windows operating systems supported: Yes
  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -20 - 60 °C
  • Operating relative humidity (H-H): 0 - 80%
  • Storage relative humidity (H-H): 0 - 80%
  • Width: 206.3 mm
  • Depth: 75.4 mm
  • Height: 44 mm
  • Weight: 960 g
  • Quick installation guide: Yes
  • Manual: Yes
  • Master (outer) case net weight: 4.8 kg
  • Harmonized System (HS) code: 85176200
  • Master (outer) case width: 232 mm
  • Master (outer) case length: 500 mm
  • Master (outer) case height: 283 mm
  • Products per master (outer) case: 5 pc(s)

Aten CS1953 — 3-Port USB-C DisplayPort Hybrid KVMP™ Switch with power adapter

€455,07
€455,07
Tax included.
