The Aten 2-Port USB 3.0 4K DisplayPort MST KVMP Switch is designed for users who need to manage multiple computers from a single workstation. It offers seamless switching between two computers and high-quality 4K video output.

  • Control two computers with a single set of peripherals, reducing desk clutter.
  • Experience high-resolution output up to 4096 x 2160 pixels at 60 Hz, ideal for detailed graphics and presentations.
  • Use multiple connection options, including DisplayPort, HDMI, and USB, providing flexibility for various devices.
  • Includes audio connections and multiple headphone and microphone inputs for enhanced multimedia use.
  • LED indicators and a push button make switching between computers straightforward and intuitive.
Specifications (1)
  • Warranty: 24 month(s)
Technical details (3)
  • Net weight: 0.73 kg
  • Producer product family: 2-Port USB 3.0 4K DisplayPort MST KVMP Switch
  • Producer product name: CS1922M-AT-G
Additional specifications (45)
  • Number of computers controlled: 2
  • Keyboard port type: USB
  • Mouse port type: USB
  • Video port type: DisplayPort
  • DisplayPorts quantity: 2
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity: 2
  • Console ports: 3.5mm headphone, 3.5mm mic, DisplayPort, HDMI, USB A
  • Console USB ports quantity: 2
  • USB hub: Yes
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity: 2
  • USB connector type: USB Type-A, USB Type-B
  • Audio connections: Yes
  • Headphone outputs: 4
  • Number of microphone inputs: 4
  • DC-in jack: Yes
  • HD type: 4K Ultra HD
  • Maximum resolution: 4096 x 2160 pixels
  • Video bandwidth: 60 Hz
  • Scan interval: 1,5,99 s
  • Firmware upgradeable: Yes
  • Product colour: Black
  • Housing material: Metal, Plastic
  • LED indicators: Yes
  • Push button: Yes
  • Hot keys: Yes
  • Built-in display: No
  • Power source: DC
  • Input voltage: 5 V
  • Power consumption (typical): 4.09 W
  • Operating temperature (T-T): 0 - 50 °C
  • Storage temperature (T-T): -20 - 60 °C
  • Operating relative humidity (H-H): 0 - 80%
  • Storage relative humidity (H-H): 0 - 80%
  • Width: 210 mm
  • Depth: 88 mm
  • Height: 55.5 mm
  • Weight: 560 g
  • Quick installation guide: Yes
  • Manual: Yes
  • Master (outer) case net weight: 2.8 kg
  • Harmonized System (HS) code: 85176200
  • Master (outer) case width: 292 mm
  • Master (outer) case length: 517 mm
  • Master (outer) case height: 194 mm
  • Products per master (outer) case: 5 pc(s)
Description

The Aten 2-Port USB 3.0 4K DisplayPort MST KVMP Switch is designed for users who need to manage multiple computers from a single workstation. It offers seamless switching between two computers and high-quality 4K video output.

  • Control two computers with a single set of peripherals, reducing desk clutter.
  • Experience high-resolution output up to 4096 x 2160 pixels at 60 Hz, ideal for detailed graphics and presentations.
  • Use multiple connection options, including DisplayPort, HDMI, and USB, providing flexibility for various devices.
  • Includes audio connections and multiple headphone and microphone inputs for enhanced multimedia use.
  • LED indicators and a push button make switching between computers straightforward and intuitive.
Specifications (1)
  • Warranty: 24 month(s)
Technical details (3)
  • Net weight: 0.73 kg
  • Producer product family: 2-Port USB 3.0 4K DisplayPort MST KVMP Switch
  • Producer product name: CS1922M-AT-G
Additional specifications (45)
  • Number of computers controlled: 2
  • Keyboard port type: USB
  • Mouse port type: USB
  • Video port type: DisplayPort
  • DisplayPorts quantity: 2
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity: 2
  • Console ports: 3.5mm headphone, 3.5mm mic, DisplayPort, HDMI, USB A
  • Console USB ports quantity: 2
  • USB hub: Yes
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity: 2
  • USB connector type: USB Type-A, USB Type-B
  • Audio connections: Yes
  • Headphone outputs: 4
  • Number of microphone inputs: 4
  • DC-in jack: Yes
  • HD type: 4K Ultra HD
  • Maximum resolution: 4096 x 2160 pixels
  • Video bandwidth: 60 Hz
  • Scan interval: 1,5,99 s
  • Firmware upgradeable: Yes
  • Product colour: Black
  • Housing material: Metal, Plastic
  • LED indicators: Yes
  • Push button: Yes
  • Hot keys: Yes
  • Built-in display: No
  • Power source: DC
  • Input voltage: 5 V
  • Power consumption (typical): 4.09 W
  • Operating temperature (T-T): 0 - 50 °C
  • Storage temperature (T-T): -20 - 60 °C
  • Operating relative humidity (H-H): 0 - 80%
  • Storage relative humidity (H-H): 0 - 80%
  • Width: 210 mm
  • Depth: 88 mm
  • Height: 55.5 mm
  • Weight: 560 g
  • Quick installation guide: Yes
  • Manual: Yes
  • Master (outer) case net weight: 2.8 kg
  • Harmonized System (HS) code: 85176200
  • Master (outer) case width: 292 mm
  • Master (outer) case length: 517 mm
  • Master (outer) case height: 194 mm
  • Products per master (outer) case: 5 pc(s)

Aten CS1922M-AT-G — 2-Port USB 3.0 4K DisplayPort MST KVMP Switch

$397.00
$397.00
Tax included.
