The Aten CS1188DP is an 8-Port USB DisplayPort Secure KVM Switch designed for efficient control of multiple computers with USB and DisplayPort connections. It supports high-definition video up to 4K Ultra HD at 3840 x 2160 pixels.

• Controls up to 8 computers using USB connections for keyboard and mouse.
• Features 8 DisplayPort inputs and 1 HDMI port for versatile video connectivity.
• Provides 16 USB 2.0 Type-B ports and console ports including 3.5mm headphone and PS/2.
• Includes headphone outputs for each connected computer and supports audio connections.
• Constructed from durable metal with LED indicators and a push button for easy switching.

Specifications

• Warranty: 24 month(s)

Technical details

• Net weight: 3.3 kg
• Producer product family: 8-Port USB DisplayPort Secure KVM Switch (PSS PP v3.0 Compliant)
• Producer product name: CS1188DP

Additional specifications

• Number of computers controlled: 8
• Keyboard port type: USB
• Mouse port type: USB
• Video port type: DisplayPort
• HDMI ports quantity: 1
• DisplayPorts quantity: 8
• USB 2.0 Type-B ports quantity: 16
• Console ports: 3.5mm headphone, HDMI, PS/2, USB A
• Console USB ports quantity: 2
• USB connector type: USB Type-B
• PS/2 ports quantity: 2
• Audio connections: Yes
• Headphone outputs: 8
• HD type: 4K Ultra HD
• Maximum resolution: 3840 x 2160 pixels
• Video bandwidth: 30 Hz
• Product colour: Black
• Housing material: Metal
• LED indicators: Yes
• Push button: Yes
• Built-in display: No
• Power source: AC
• Input voltage: 100 - 240 V
• AC input frequency: 50 - 60 Hz
• Input current: 1 A
• Power consumption (typical): 9.7 W
• Windows operating systems supported: Yes
• Compliance certificates: RoHS
• Operating temperature (T-T): 0 - 50 °C
• Storage temperature (T-T): -20 - 60 °C
• Operating relative humidity (H-H): 0 - 80%
• Width: 204.9 mm
• Depth: 432.4 mm
• Height: 65.5 mm
• Weight: 3.21 kg
• Cables included: AC
• Quick installation guide: Yes
• Manual: Yes
• Master (outer) case net weight: 9.63 kg
• Harmonized System (HS) code: 85176200
• Master (outer) case width: 427 mm
• Master (outer) case length: 519 mm
• Master (outer) case height: 348 mm
• Products per master (outer) case: 3 pc(s)
