The Aten CS1184H is a 4-Port USB HDMI Secure KVM switch designed to control up to four computers. It supports 4K Ultra HD resolution and offers robust connectivity options for both USB and HDMI devices.

• Controls up to 4 computers
• Supports HDMI with a maximum resolution of 3840 x 2160 pixels
• Includes 8 USB 2.0 Type-B ports and 2 console USB ports
• Equipped with 4 headphone outputs and audio connections
• 1U rack mountable metal housing

Specifications

• Warranty: 24 month(s)

Technical details

• Net weight: 1.76 kg
• Producer product family: 4-Port USB HDMI Secure KVM Switch (PSS PP v3.0 Compliant)
• Producer product name: CS1184H

Additional specifications

• Number of computers controlled: 4
• Keyboard port type: USB
• Mouse port type: USB
• Video port type: HDMI
• HDMI ports quantity: 4
• USB 2.0 Type-B ports quantity: 8
• Console ports: HDMI, PS/2, USB A
• Console USB ports quantity: 2
• Audio connections: Yes
• Headphone outputs: 4
• Ethernet LAN: No
• HD type: 4K Ultra HD
• Maximum resolution: 3840 x 2160 pixels
• Rack mounting: Yes
• Rack capacity: 1U
• Product colour: Black
• Housing material: Metal
• LED indicators: Yes
• Push button: Yes
• Built-in display: No
• Power source: AC
• Input voltage: 100 - 240 V
• AC input frequency: 50 - 60 Hz
• Input current: 1 A
• Windows operating systems supported: Yes
• Compliance certificates: RoHS
• Operating temperature (T-T): 0 - 50 °C
• Storage temperature (T-T): -20 - 60 °C
• Operating relative humidity (H-H): 0 - 80%
• Width: 335 mm
• Depth: 163.4 mm
• Height: 44 mm
• Weight: 1.94 kg
• Cables included: AC
• Quick installation guide: Yes
• Master (outer) case net weight: 5.82 kg
• Harmonized System (HS) code: 85176200
• Master (outer) case width: 375 mm
• Master (outer) case length: 565 mm
• Master (outer) case height: 258 mm
• Products per master (outer) case: 3 pc(s)
