The Aten CS1184DP is a 4-Port USB DisplayPort Secure KVM Switch designed for managing multiple computers efficiently. It supports 4K Ultra HD resolution at 3840 x 2160 pixels and features various connectivity options including multiple DisplayPort and USB ports.

• Controls up to 4 computers with DisplayPort connectivity
• Supports USB keyboard and mouse connections
• Includes 4 DisplayPorts and 1 HDMI port for versatile video output
• Offers audio connections with 4 headphone outputs
• Constructed with a metal housing for durability and reliability

Specifications

• Warranty: 24 month(s)

Technical details

• Net weight: 2.00 kg
• Producer product family: 4-Port USB DisplayPort Secure KVM Switch (PSS PP v3.0 Compliant)
• Producer product name: CS1184DP

Additional specifications

• Number of computers controlled: 4
• Keyboard port type: USB
• Mouse port type: USB
• Video port type: DisplayPort
• HDMI ports quantity: 1
• DisplayPorts quantity: 4
• USB 2.0 Type-B ports quantity: 8
• Console ports: 3.5mm headphone, HDMI, PS/2, USB A
• Console USB ports quantity: 2
• USB connector type: USB Type-B
• PS/2 ports quantity: 2
• Audio connections: Yes
• Headphone outputs: 4
• HD type: 4K Ultra HD
• Maximum resolution: 3840 x 2160 pixels
• Video bandwidth: 30 Hz
• Rack mounting: Yes
• Product colour: Black
• Housing material: Metal
• LED indicators: Yes
• Push button: Yes
• Built-in display: No
• Power source: AC
• Input voltage: 100 - 240 V
• AC input frequency: 50 - 60 Hz
• Input current: 1 A
• Power consumption (typical): 4.7 W
• Windows operating systems supported: Yes
• Compliance certificates: RoHS
• Operating temperature (T-T): 0 - 50 °C
• Storage temperature (T-T): -20 - 60 °C
• Operating relative humidity (H-H): 0 - 80%
• Width: 164.3 mm
• Depth: 335 mm
• Height: 44 mm
• Weight: 2 kg
• Cables included: AC
• Quick installation guide: Yes
• Manual: Yes
• Master (outer) case net weight: 6 kg
• Harmonized System (HS) code: 85176200
• Master (outer) case width: 375 mm
• Master (outer) case length: 565 mm
• Master (outer) case height: 258 mm
• Products per master (outer) case: 3 pc(s)
