About

Description

The Aten CE604 USB DVI Dual View Cat 5 KVM Extender is designed for users who need to control two DVI monitors from a single computer remotely. This device is ideal for settings where workspace flexibility and dual monitor functionality are required.

  • Transmits video and audio signals over distances up to 60 m, allowing for remote computer access without compromising on quality.
  • Supports resolutions up to 1920 x 1200, ensuring clear visuals for various applications.
  • Features manual compensation control to fine-tune video signal quality based on the distance, providing reliable performance in different setups.
  • Includes dual view support for computers with two video output ports, enhancing productivity by enabling simultaneous monitoring.
  • Equipped with a metal casing for durability and stability, suitable for rack mounting in professional environments.
Specifications (4)
  • Producer product family: USB DVI Dual View Cat 5 KVM Extender
  • Producer product name: CE604
  • Cable: 1 x Custom KVM Cable (DVI-D Single Link, USB, Audio; (1.8m); 1 x DVI Cable (1.8m)
  • Warranty: 24 month(s)
Other features (2)
  • I/O ports: Console Ports: 2 x USB Type A Female (White); 2 x DVI-D Female (White); 1 x Mini Stereo Jack Female (Green); 1 x Mini Stereo Jack Female (Pink). KVM Ports: 1 x USB Type B Female (White) 1 x Mini Stereo Jack Female (Green) 1 x Mini Stereo Jack Female (Pink) 2 x DVI-D Female (White)
  • Resolution: 1920 x 1200 @ 60Hz (30 m); 1024 x 768 @ 60Hz (60 m)
Technical details (2)
  • Net weight: 0.49 kg
  • Other features: Supports Dual View video source transmission (one PC with two video output ports); Manual compensation control to adjust video signal quality in order to compensate for distance
Additional specifications (38)
  • Type: Transmitter & receiver
  • Connectivity technology: Wired
  • Maximum transfer distance: 60 m
  • Cable types supported: Cat5, Cat5e
  • Rack mounting: Yes
  • Maximum digital resolution: 1920 x 1200 pixels
  • Supported resolutions: 1920 x 1200, 1024 x 768
  • Product colour: Black
  • Material: Metal
  • LED indicators: Link, Power
  • Transmitter video port type: DVI-D
  • Transmitter local keyboard/mouse port type: USB
  • RJ-45 ports quantity (transmitter): 2
  • Receiver local video port type: DVI-D
  • Receiver local keyboard/mouse port type: USB
  • RJ-45 ports quantity (receiver): 2
  • AC adapter output voltage: 5.3 V
  • Transmitter width: 20.2 cm
  • Transmitter depth: 8.53 cm
  • Transmitter height: 2.5 cm
  • Transmitter weight: 490 g
  • Receiver width: 20.2 cm
  • Receiver depth: 8.67 cm
  • Receiver height: 2.5 cm
  • Receiver weight: 490 g
  • Manual: Yes
  • Quick installation guide: Yes
  • Operating temperature (T-T): 0 - 50 °C
  • Storage temperature (T-T): -20 - 60 °C
  • Operating relative humidity (H-H): 0 - 80%
  • Storage relative humidity (H-H): 0 - 80%
  • Weight: 1.99 kg
  • Master (outer) case net weight: 9.95 kg
  • Harmonized System (HS) code: 84733080
  • Master (outer) case width: 342 mm
  • Master (outer) case length: 512 mm
  • Master (outer) case height: 232 mm
  • Products per master (outer) case: 5 pc(s)
Description

The Aten CE604 USB DVI Dual View Cat 5 KVM Extender is designed for users who need to control two DVI monitors from a single computer remotely. This device is ideal for settings where workspace flexibility and dual monitor functionality are required.

  • Transmits video and audio signals over distances up to 60 m, allowing for remote computer access without compromising on quality.
  • Supports resolutions up to 1920 x 1200, ensuring clear visuals for various applications.
  • Features manual compensation control to fine-tune video signal quality based on the distance, providing reliable performance in different setups.
  • Includes dual view support for computers with two video output ports, enhancing productivity by enabling simultaneous monitoring.
  • Equipped with a metal casing for durability and stability, suitable for rack mounting in professional environments.
Specifications (4)
  • Producer product family: USB DVI Dual View Cat 5 KVM Extender
  • Producer product name: CE604
  • Cable: 1 x Custom KVM Cable (DVI-D Single Link, USB, Audio; (1.8m); 1 x DVI Cable (1.8m)
  • Warranty: 24 month(s)
Other features (2)
  • I/O ports: Console Ports: 2 x USB Type A Female (White); 2 x DVI-D Female (White); 1 x Mini Stereo Jack Female (Green); 1 x Mini Stereo Jack Female (Pink). KVM Ports: 1 x USB Type B Female (White) 1 x Mini Stereo Jack Female (Green) 1 x Mini Stereo Jack Female (Pink) 2 x DVI-D Female (White)
  • Resolution: 1920 x 1200 @ 60Hz (30 m); 1024 x 768 @ 60Hz (60 m)
Technical details (2)
  • Net weight: 0.49 kg
  • Other features: Supports Dual View video source transmission (one PC with two video output ports); Manual compensation control to adjust video signal quality in order to compensate for distance
Additional specifications (38)
  • Type: Transmitter & receiver
  • Connectivity technology: Wired
  • Maximum transfer distance: 60 m
  • Cable types supported: Cat5, Cat5e
  • Rack mounting: Yes
  • Maximum digital resolution: 1920 x 1200 pixels
  • Supported resolutions: 1920 x 1200, 1024 x 768
  • Product colour: Black
  • Material: Metal
  • LED indicators: Link, Power
  • Transmitter video port type: DVI-D
  • Transmitter local keyboard/mouse port type: USB
  • RJ-45 ports quantity (transmitter): 2
  • Receiver local video port type: DVI-D
  • Receiver local keyboard/mouse port type: USB
  • RJ-45 ports quantity (receiver): 2
  • AC adapter output voltage: 5.3 V
  • Transmitter width: 20.2 cm
  • Transmitter depth: 8.53 cm
  • Transmitter height: 2.5 cm
  • Transmitter weight: 490 g
  • Receiver width: 20.2 cm
  • Receiver depth: 8.67 cm
  • Receiver height: 2.5 cm
  • Receiver weight: 490 g
  • Manual: Yes
  • Quick installation guide: Yes
  • Operating temperature (T-T): 0 - 50 °C
  • Storage temperature (T-T): -20 - 60 °C
  • Operating relative humidity (H-H): 0 - 80%
  • Storage relative humidity (H-H): 0 - 80%
  • Weight: 1.99 kg
  • Master (outer) case net weight: 9.95 kg
  • Harmonized System (HS) code: 84733080
  • Master (outer) case width: 342 mm
  • Master (outer) case length: 512 mm
  • Master (outer) case height: 232 mm
  • Products per master (outer) case: 5 pc(s)

Aten CE604 — USB DVI Dual View Cat 5 KVM Extender

€694,39
€694,39
Tax included.
