Description

The Acer S1386WH is a DLP projector designed for home and office use, offering a bright and clear image for presentations and entertainment. With a medium throw ratio and versatile projection distance, it suits a range of screen sizes from 36 to 300 inches.

3600 ANSI lumens brightness ensures clear visibility even in well-lit rooms.
Native WXGA resolution (1280x800) provides detailed images for professional presentations.
A wide contrast ratio of 20000:1 enhances image depth and clarity.
Keystone correction up to ±40° allows for flexible setup and alignment.
Supports a variety of aspect ratios, including 4:3 and 16:9, to match different content formats.

Design (2)

Colour of product: White
Producer product family: DLP Projector

Technical details (5)

Brightness: 3600 ANSI lumens
Producer product name: S1386WH
Contrast ratio: 20000:1
Maximum resolution: WXGA (1280x800)
Net weight: 3.10 kg

Specifications (1)

Warranty: 36 month(s)

Lens system (1)

Throw ratio: 0.52:1

Networking (1)

Wi-Fi connection: No

Other features (1)

Aspect ratio: 16:10

Projector (1)

Projector native resolution: 1280 x 800

Additional specifications (60)

Supported aspect ratios: 4:3, 16:9
Screen size compatibility: 914.4 - 7620 mm (36 - 300")
Projection distance: 0.4 - 3.4 m
Projector brightness: 3600 ANSI lumens
Projection technology: DLP
Contrast ratio (typical): 20000:1
Native aspect ratio: 16:10
Number of colours: 1.073 billion colours
Keystone correction, vertical: -40 - 40°
Horizontal synchronization (min): 15 kHz
Horizontal synchronization (max): 100 kHz
Vertical synchronization (min): 0.024 kHz
Vertical synchronization (max): 0.12 kHz
Light source type: Lamp
Service life of light source: 5000 h
Service life of light source (economic mode): 6000 h
Lamp type: OSRAM
Lamp power: 220 W
Lamps quantity: 1 lamp(s)
Focus: Manual
Fixed focal length: 7.51 mm
Aperture range (F-F): 2.8 - 2.8
Digital zoom: 2x
Optical zoom: 1x
Analog signal format system: NTSC, PAL, SECAM
Supported graphics resolutions: 1280 x 800 (WXGA)
Audio (L/R) in: 1
Audio (L/R) out: 1
VGA (D-Sub) ports quantity: 2
HDMI ports quantity: 1
Composite video in: 1
DC-in jack: Yes
Card reader integrated: No
Noise level (economic mode): 24 dB
Projection modes: Ceiling, Front, Rear
Noise level: 32 dB
Built-in speaker(s): Yes
RMS rated power: 16 W
Number of built-in speakers: 1
Market positioning: Education
Product type: Standard throw projector
Product colour: White
Housing material: Plastic
Placement: Ceiling
LED indicators: Yes
Built-in display: No
Power source: AC
Power consumption (typical): 270 W
Power consumption (PowerSave): 210 W
AC input voltage: 120 - 230 V
Windows operating systems supported: Yes
Mac compatibility: Yes
Mac operating systems supported: Yes
Operating temperature (T-T): 0 - 40 °C
Weight: 3.1 kg
Remote control included: Yes
Remote control type: IR
Quick start guide: Yes
Harmonized System (HS) code: 85286200
Maximum digital resolution: 1920 x 1200 pixels
