Bosch UniversalDrill 18

Bosch UniversalDrill 18 cordless drill driver: exploded parts diagram, 2 sheets, 22 positions. Spare parts with part numbers, availability and prices.

—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch UniversalDrill 18: 22 positions on 2 sheets

Bosch UniversalDrill 18 parts list (2 sheets)

Bosch UniversalDrill 18 parts diagram, sheet 1Bosch UniversalDrill 18 parts diagram, sheet 2
No.Part numberPart name
116058065VRHousing
1012609110201Torx Flat-Head Screw 3X16
1072603421229Countersunk-Head Screw Lefthand Threads M6X23
221600A01AS2Symbol plate
251600A0103SKeyless Chuck
321600A01B09Switchover Unit
322609199353Switchover Unit
42607202396Electronics Module
451600A01B0AGear Box
51600A01AA2Change-Over Switch
6501600A013NMCarrying Case
6532607226385Fast Charger EU AL 1810 CV 230/14,4-18V 1A
6532607226389Fast Charger Aus AL1810CV
6532607226395Fast Charger Jp AL1810CV
6532607226517Charger EU AL 18V-20 230V 2A
6542609160063Screwdriver Bit
8021600A01DD0Motor assembly
808160111A6KGNameplate
808160111A78LNameplate
808160111A78NNameplate
911607A350JMBattery Pack PBA 18V/1,5 Ah W-a
911607A350P5Battery Pack Jp PBA 1,5 Ah W-a
Selected parts0
