Bosch UniversalCut 18V-85 cordl reciprocating saw: exploded parts diagram, 1 sheet, 25 positions. Spare parts with part numbers, availability and prices.
—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch UniversalCut 18V-85: 25 positions on 1 sheet
Bosch UniversalCut 18V-85 parts list (1 sheet)
| No. | Part number | Part name |
|---|---|---|
| 1 | 16058066DZ | Housing |
| 15 | 2600910001 | Needle-Roller Bearing Ø14 MM |
| 16 | 1600A003HJ | Pin |
| 17 | 1600A00495 | Flap |
| 18 | 1600A003SD | Tensioning device |
| 19 | 1604612012 | Compression Spring |
| 20 | 1600A00496 | Clamping Lever |
| 21 | 1600A0034V | Base Plate |
| 22 | 1605808091 | Bearing Flange |
| 23 | 1605806586 | Housing |
| 24 | 1600A00F9P | Riving Knife |
| 25 | 1600A003SB | Pin |
| 26 | 1600A007RM | Lever |
| 27 | 160111C4U5 | Sticker |
| 28 | 2609110201 | Torx Flat-Head Screw 3X16 |
| 29 | 2609110361 | Screw |
| 3 | 2607202571 | Electronic Assembly |
| 4 | 1600A02AM7 | Lever |
| 5 | 1600A007HY | Spring |
| 653 | 2607226517 | Charger EU AL 18V-20 230V 2A |
| 653 | 2607226519 | Charger UK AL 18V-20 230V 2A |
| 802 | 16070226BE | DC motor |
| 808 | 160111A9VZ | Nameplate |
| 812 | 1600A02NH1 | Drive Shaft |
| 91 | 1607A350RU | Battery Pack PBA 18V 2,5AH W-b 45WH |
