Bosch PS82
Bosch PS82 impact wrench: exploded parts diagram, 1 sheet, 21 positions. Spare parts with part numbers, availability and prices.
—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch PS82: 21 positions on 1 sheet
Bosch PS82 parts list (1 sheet)
| No. | Part number | Part name |
|---|---|---|
| 1 | 2609101235 | Housing |
| 101 | 2609110883 | Screw |
| 102 | 2609110537 | Clip |
| 105 | 2609101394 | Color clip |
| 4 | 1607233581 | Electronics Module |
| 41 | 2609134168 | Sticker |
| 42 | 2609134169 | Sticker |
| 45 | 2609199731 | Gear Box |
| 45/27 | 2609111678 | Metal Ring |
| 45/28 | 2609170227 | O-Ring |
| 5 | 2609101236 | Adjusting lever |
| 6 | 2609101237 | Button |
| 653 | 2607225139 | Fast Charger Usa/can 120/10,8-12V/30 Min. |
| 653 | 2607225519 | Fast Charger USA 120/3,6-10,8V,1H |
| 8 | 160111C334 | Warning Plate |
| 802 | 2609199661 | Brushless DC motor |
| 808 | 160111A6VL | Nameplate |
| 855 | 2609199986 | Clip |
| 9 | 2609136080 | Manufacturer's nameplate Lithium-Ion 12V |
| 91 | 1607A350C8 | Battery Pack BAT 414 10,8/12V 2,0AH |
| 91 | 2607337237 | Battery Pack BAT 415 10,8V712V 2,5AH |
