Bosch PEX 11 A-1 random orbital sander: exploded parts diagram, 2 sheets, 57 positions. Spare parts with part numbers, availability and prices.
—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch PEX 11 A-1: 57 positions on 2 sheets
Bosch PEX 11 A-1 parts list (2 sheets)
| No. | Part number | Part name |
|---|---|---|
| 1 | 2605104287 | Housing Section Green |
| 12 | 1607328028 | Suppression Filter |
| 13 | 2605805005 | Cartridge bearing |
| 16 | 2604337118 | Brush Plate |
| 16 | 2605807121 | Brush Plate |
| 18 | 2603410001 | Socket head cap screw M3X6,5-4.8 |
| 19 | 2603490021 | Torx Oval-Head Screw 4X12 |
| 2 | 2604220535 | Field 220-240V |
| 2 | 2604220546 | Field 115-120V |
| 28 | 2915121006 | Square Nut DIN 562-M6-04 |
| 3 | 2604011014 | Armature 220-240V |
| 3 | 2604011041 | Armature 115-120V |
| 3/50 | 2606610055 | Fan |
| 35 | 2910975197 | Hex Socket Head Cap Screw DIN 7984-M6X16-10.9 |
| 36 | 2600210036 | O-Ring 5,0X1,75 MM |
| 38 | 2604448109 | Connecting Cable White L=115 MM |
| 39 | 2604448140 | Cable White L=103MM |
| 4 | 2607200260 | Switch |
| 40 | 2601022000 | Damping Plate |
| 41 | 1614431010 | Cable White L=233 MM |
| 42 | 2600190150 | Plain Washer |
| 43 | 2603490023 | Torx Oval-Head Screw 4X20 |
| 45 | 2603490022 | Screw 4X16 |
| 5 | 2604460124 | Power supply cord GB 240V 2,65M 2 X 1,0MM H05 Vv-F |
| 5 | 2604460125 | Power supply cord CH 2,65M 2 X 1,0MM H05VV-F |
| 5 | 2604460126 | Power supply cord AUS 2,6M 2 X 0,75MM Pvc |
| 5 | 2604460129 | Power supply cord Usa/cdn 2,15M 2 X 082MM SJ 18/2 |
| 5 | 2604460280 | Power supply cord I / BR 2,65M 2 X 1,0MM H05VV-F |
| 6 | 2600703031 | Grommet Ø6,5-Ø6,9X95 MM |
| 6 | 2600703032 | Grommet Ø7,6-Ø8,2X95 MM |
| 655 | 2605702029 | Fitting |
| 656 | 2607950004 | Offset Screwdriver DIN 911-4 |
| 7 | 2601035004 | Cable Clip |
| 733 | 2608601064 | Backing Pad Ø 115 MM |
| 733 | 2608601065 | Backing Pad Ø 115 MM |
| 733 | 2608601066 | Backing Pad Ø 115 MM |
| 752 | 2600282002 | Suction Hood Ø 115 MM |
| 754 | 2605411009 | Dust Bag |
| 754 | 2605411025 | Dust Bag |
| 754 | 2605411026 | Dust Bag 5 Piece |
| 754 | 2605411027 | Dust Bag With Adapter |
| 756 | 2602026046 | Handle Black M6X15 MM |
| 757 | 1609200976 | Suction Pipe Ø 49/35 MM |
| 805 | 1607000388 | Power supply cord EU 2,65M 2 X 1,0MM H05 Rn-F |
| 808 | 2601119222 | Marking Plate |
| 808 | 2601119223 | Marking Plate |
| 808 | 2601119224 | Reference Plate |
| 808 | 2601119225 | Reference Plate |
| 808 | 2601119226 | Reference Plate |
| 808 | 2601119227 | Reference Plate |
| 816/04 | 2604321914 | Carbon-Brush Set |
| 816/04 | 2604321917 | Carbon-Brush Set |
| 816/05 | 2604610026 | Compression Spring |
| 816/06 | 2601322013 | Ratchet Cap |
| 816/06 | 2601329051 | Ratchet Cap |
| 826 | 2606610900 | Fan Lefthand Threads |
| 9 | 2601118405 | Manufacturer's nameplate |
