Bosch PB10-CD
Bosch PB10-CD radio receiver: exploded parts diagram, 1 sheet, 25 positions. Spare parts with part numbers, availability and prices.
—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch PB10-CD: 25 positions on 1 sheet
Bosch PB10-CD parts list (1 sheet)
| No. | Part number | Part name |
|---|---|---|
| 801 | 2610923571 | Dummy |
| 802 | 2610923572 | Door |
| 803 | 2610923573 | Spring Plate |
| 804 | 2610923574 | Hinge |
| 805 | 2610923575 | Door lock |
| 806 | 2610923576 | Battery Tray |
| 807 | 2610923577 | Cord |
| 808 | 2610923578 | Holding Fixture |
| 809 | 2610923579 | Grommet |
| 810 | 2610923580 | Sticker |
| 811 | 2610923581 | Longitudinal Strut |
| 812 | 2610923582 | Assembly Frame |
| 813 | 2610923583 | Elbow Piece |
| 814 | 2610923584 | Terminal lug |
| 815 | 2610923585 | Cover |
| 816 | 2610923586 | Dummy |
| 817 | 2610923587 | Dummy |
| 818 | 2610923588 | Dummy |
| 819 | 2610923589 | Dummy |
| 820 | 2610923590 | Assembly Kit |
| 821 | 2610925222 | Antenna Housing |
| 823 | 2610925218 | Antenna |
| 828 | 2610911248 | Fuse |
| 829 | 2910141203 | Hex Socket Head Cap Screw DIN 912-M6X25-8.8 |
| 830 | 2910141213 | Hex Socket Head Cap Screw DIN 912-M6X50-8.8 |
