Bosch MSW 150
Bosch MSW 150 orbital sander: exploded parts diagram, 1 sheet, 101 positions. Spare parts with part numbers, availability and prices.
—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch MSW 150: 101 positions on 1 sheet
Bosch MSW 150 parts list (1 sheet)
| No. | Part number | Part name |
|---|---|---|
| 11 | 1607328028 | Suppression Filter |
| 11 | 1607328028 | Suppression Filter |
| 12 | 2605510008 | Pressure Bar |
| 12 | 2605510008 | Pressure Bar |
| 15 | 2604448001 | Connecting Cable White L=184 MM |
| 15 | 2604448001 | Connecting Cable White L=184 MM |
| 16 | 2604610009 | Compression Spring |
| 16 | 2604610009 | Compression Spring |
| 17 | 2600910005 | Needle bearing |
| 17 | 2600910005 | Needle bearing |
| 18 | 1610210014 | O-Ring 8,0X2,5 MM |
| 18 | 1610210014 | O-Ring 8,0X2,5 MM |
| 19 | 1604449002 | Brush Holder |
| 19 | 2604465081 | Suppressor Box |
| 19 | 2604465081 | Suppressor Box |
| 2 | 1604220149 | Field 220-230V |
| 2 | 1604220152 | Field 240V |
| 2 | 2604220423 | Field 220-240V |
| 2 | 1604220149 | Field 220-230V |
| 20 | 2601110981 | Sticker Shadow Side |
| 20 | 2601118236 | Sticker Shadow Side |
| 22 | 2601022000 | Damping Plate |
| 22 | 2601022000 | Damping Plate |
| 24 | 1603101018 | Round Rubber Ø 11,3X23,5 MM |
| 24 | 1603101018 | Round Rubber Ø 11,3X23,5 MM |
| 25 | 2600100041 | Plain Washer DIN 315-M8-GT-C |
| 25 | 2600100041 | Plain Washer DIN 315-M8-GT-C |
| 26 | 1600100020 | Plain Washer |
| 26 | 1600100020 | Plain Washer |
| 27 | 2602210009 | Eccentric Disc |
| 27 | 2602210009 | Eccentric Disc |
| 28 | 2600905013 | Groove ball bearing 12X28X8 |
| 28 | 2600905013 | Groove ball bearing 12X28X8 |
| 29 | 2600501004 | Bearing Flange |
| 29 | 2600501004 | Bearing Flange |
| 3/50 | 2606610027 | Fan |
| 30 | 1903230004 | Ball DIN 5401-3 Mm-Iii-St |
| 30 | 1903230004 | Ball DIN 5401-3 Mm-Iii-St |
| 31 | 1900210128 | O-Ring 28X2,5 MM |
| 31 | 1900210128 | O-Ring 28X2,5 MM |
| 33 | 1900905122 | Groove ball bearing 15X32X9 |
| 33 | 1900905162 | Groove ball bearing 15X32X9 |
| 33 | 2600905068 | Groove ball bearing 15X32X9 |
| 33 | 1900905122 | Groove ball bearing 15X32X9 |
| 34 | 2603410001 | Socket head cap screw M3X6,5-4.8 |
| 34 | 2603410001 | Socket head cap screw M3X6,5-4.8 |
| 35 | 1601329009 | Clamping Saddle |
| 35 | 1601329009 | Clamping Saddle |
| 36 | 1603201023 | Straight Pin |
| 36 | 1603201023 | Straight Pin |
| 37 | 1604651004 | Coiled Spring |
| 37 | 1604651004 | Coiled Spring |
| 38 | 2603490022 | Screw 4X16 |
| 38 | 2910611019 | Tapping Screw DIN 7981-ST3,9X16-C-H |
| 39 | 2910021154 | Socket head cap screw DIN 84-AM5X12-8.8 |
| 39 | 2910021154 | Socket head cap screw DIN 84-AM5X12-8.8 |
| 4 | 2607200084 | Switch |
| 4 | 2607200131 | On-Off Switch |
| 4 | 2607200260 | Switch |
| 4 | 2607200084 | Switch |
| 40 | 2916060006 | Spring Washer DIN 137-A5-FST |
| 40 | 2916060006 | Spring Washer DIN 137-A5-FST |
| 41 | 2916660011 | Spring retaining ring DIN 472-28X1,2 MM |
| 41 | 2916660011 | Spring retaining ring DIN 472-28X1,2 MM |
| 5 | 1604460023 | Power supply cord |
| 5 | 1604460024 | Power supply cord |
| 5 | 1607000388 | Power supply cord EU 2,65M 2 X 1,0MM H05 Rn-F |
| 5 | 2604460125 | Power supply cord CH 2,65M 2 X 1,0MM H05VV-F |
| 5 | 2604460127 | Power supply cord J 2,50M 2 X 0,75MM Pvc |
| 5 | 2604460129 | Power supply cord Usa/cdn 2,15M 2 X 082MM SJ 18/2 |
| 5 | 2604460139 | Power supply cord AUS 2,6M 2 X 0,75MM Pvc |
| 5 | 2604460280 | Power supply cord I / BR 2,65M 2 X 1,0MM H05VV-F |
| 5 | 3607030489 | Power supply cord |
| 5 | 2604460125 | Power supply cord CH 2,65M 2 X 1,0MM H05VV-F |
| 6 | 2600703006 | Grommet Ø9,5 MM |
| 6 | 2600703007 | Grommet Ø7 MM |
| 6 | 2600703008 | Grommet Ø8,2 MM |
| 6 | 2600703007 | Grommet Ø7 MM |
| 657 | 1608604143 | Set Of Sanding Papers KORN 320 |
| 657 | 1608604143 | Set Of Sanding Papers KORN 320 |
| 7 | 2601035001 | Cable Clip |
| 7 | 2601035001 | Cable Clip |
| 700 | 1605190018 | Suction Frame |
| 700 | 1605190024 | Suction Frame |
| 700 | 1605190018 | Suction Frame |
| 801 | 2605104997 | Housing Section Green |
| 802 | 1604220151 | Field 240V |
| 803 | 1604010228 | Armature 220-230V |
| 803 | 1604010229 | Armature 100-110V |
| 803 | 1604010230 | Armature 240V |
| 803 | 1604010231 | Armature 115V |
| 805 | 1607000386 | Power supply cord EU 230V 4,15M 2 X 1,0MM H05 Rn-F |
| 808 | 160111A3H3 | Nameplate |
| 810 | 1604321900 | Carbon Brush |
| 810 | 2604321904 | Carbon-Brush Set |
| 810 | 1604321900 | Carbon Brush |
| 823 | 1607000902 | Parts Set |
| 823 | 1607000902 | Parts Set |
| 9 | 1601110151 | Sticker Sunny Side |
| 9 | 2601110602 | Sticker Sunny Side |
| 9 | 2601118204 | Sticker Sunny Side |
