Bosch 0601999005

Bosch 0601999005 cutting stand: exploded parts diagram, 1 sheet, 26 positions. Spare parts with part numbers, availability and prices.

—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch 0601999005: 26 positions on 1 sheet

Bosch 0601999005 parts list (1 sheet)

Bosch 0601999005 parts diagram, sheet 1
No.Part numberPart name
11608000011Base Plate
11609390214Square Nut
101603200008Pressure Spindle
101609390223Base Plate
111602027009Clamping Lever
111609390224Miter Square
121603105003Pivot Pin
121609390225Bearing Pedestal
21600700005Guide Tube
21609390215Tensioning device
222911061201Hex Screw M 6X20 DIN 933-8.8
31608040100Retaining Bracket
31609390216Drive-Machine Holder
41608040018Clamping Piece
41609390217Coiled Spring
51604615008Compression Spring
51609390218Swivelling Lever
61601315029Depth-Gauge
61609390219Hex Screw
6511607950009Offset Screwdriver SW8
71603000005Holding Pin
71609390220Protective Shield
81602316000Strap
81609390221End stop
91601901002Feed Lever
91609390222Holding Bracket
