Bosch GSS 180 orbital sander: exploded parts diagram, 1 sheet, 76 positions. Spare parts with part numbers, availability and prices.
—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch GSS 180: 76 positions on 1 sheet
Bosch GSS 180 parts list (1 sheet)
| No. | Part number | Part name |
|---|---|---|
| 1 | 2605105023 | Housing Section Blue |
| 1 | 2605105023 | Housing Section Blue |
| 10 | 2604337091 | Brush Plate |
| 10 | 2604337088 | Brush Plate |
| 13 | 2600905078 | Groove ball bearing |
| 13 | 2600905078 | Groove ball bearing |
| 15 | 2606610113 | Fan |
| 15 | 2606610113 | Fan |
| 19 | 2603490022 | Screw 4X16 |
| 19 | 2603490022 | Screw 4X16 |
| 2 | 2604220672 | Field 115V |
| 2 | 2604220673 | Field 230-240V |
| 2 | 2604220672 | Field 115V |
| 2 | 2604220673 | Field 230-240V |
| 21 | 2608000238 | Sander Plate |
| 21 | 2608000238 | Sander Plate |
| 24 | 2600290039 | Seal Ring |
| 24 | 2600290039 | Seal Ring |
| 25 | 2604448247 | Connecting Cable Blue L=160 MM |
| 25 | 2604448247 | Connecting Cable Blue L=160 MM |
| 26 | 3604440527 | Connecting Cable White L=63 MM |
| 26 | 3604440527 | Connecting Cable White L=63 MM |
| 28 | 2603100056 | Damping rubber |
| 28 | 2609000549 | Rubber Buffer |
| 3 | 2604011275 | Armature 115V |
| 3 | 2604011276 | Armature 230-240V |
| 3 | 2604011275 | Armature 115V |
| 3 | 2604011276 | Armature 230-240V |
| 4 | 2607200526 | Switch |
| 4 | 2607200526 | Switch |
| 5 | 1607000387 | Power supply cord CN 2,65M 2 X 0,75MM H05 W-f |
| 5 | 2604460153 | Power supply cord J 2,5M 2 X 0,75MM Pvc |
| 5 | 2604460243 | Power supply cord GB 230V 2,65M 2 X 1,0MM H05 Vv-F |
| 5 | 2604460245 | Power supply cord CN 220V 2,65M 2 X 0,75MM H05 Vv-F |
| 5 | 1604460236 | Power supply cord AR 2,7M 2 X 1,0MM H05 Vv-F |
| 5 | 1607000387 | Power supply cord CN 2,65M 2 X 0,75MM H05 W-f |
| 5 | 2604460153 | Power supply cord J 2,5M 2 X 0,75MM Pvc |
| 5 | 2604460243 | Power supply cord GB 230V 2,65M 2 X 1,0MM H05 Vv-F |
| 5 | 2604460245 | Power supply cord CN 220V 2,65M 2 X 0,75MM H05 Vv-F |
| 5 | 2604460249 | Power supply cord SAM 2,7M 2 X 0,82MM SJ 18/2 |
| 5 | 2604460283 | Power supply cord I/br 2,65M 2 X 1,0MM H05 Vv-F |
| 50 | 2605411121 | Dust container 1 Piece |
| 50 | 2605411121 | Dust container 1 Piece |
| 6 | 2600703017 | Grommet Ø6,4-Ø7,2X76 MM |
| 6 | 2600703019 | Grommet Ø8,7-Ø9,6X76 MM |
| 6 | 2600703018 | Grommet Ø7,3-Ø8,6X76 MM |
| 6 | 2600703019 | Grommet Ø8,7-Ø9,6X76 MM |
| 6 | 2609002019 | Grommet |
| 7 | 2603490017 | Torx Oval-Head Screw 3X10 |
| 7 | 2603490017 | Torx Oval-Head Screw 3X10 |
| 803 | 2604010980 | Armature 230-240V |
| 803 | 2604010987 | Armature 115V |
| 803 | 2604010980 | Armature 230-240V |
| 803 | 2604010987 | Armature 115V |
| 808 | 2601116033 | Nameplate |
| 808 | 2601116034 | Nameplate |
| 808 | 2601116035 | Nameplate |
| 808 | 2601116036 | Nameplate |
| 808 | 2601116439 | Nameplate |
| 808 | 2601116620 | Nameplate |
| 808 | 2601116621 | Nameplate |
| 808 | 2601116622 | Nameplate |
| 808 | 2601116623 | Nameplate |
| 808 | 2601116624 | Nameplate |
| 808 | 2609000414 | Nameplate |
| 808 | 2609000415 | Nameplate |
| 808 | 2609000431 | Nameplate |
| 808 | 2609000432 | Nameplate |
| 811 | 2604321925 | Carbon-Brush Set |
| 811 | 2604321925 | Carbon-Brush Set |
| 819 | 2600905045 | Groove ball bearing 12X28X8 |
| 819 | 2600905045 | Groove ball bearing 12X28X8 |
| 821 | 1611110G45 | Reference Plate |
| 821 | 1601110G87 | Reference Plate |
| 9 | 2601116043 | Manufacturer's nameplate |
| 9 | 2601116043 | Manufacturer's nameplate |
