Bosch GSS 18 A
Bosch GSS 18 A orbital sander: exploded parts diagram, 1 sheet, 85 positions. Spare parts with part numbers, availability and prices.
—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch GSS 18 A: 85 positions on 1 sheet
Bosch GSS 18 A parts list (1 sheet)
| No. | Part number | Part name |
|---|---|---|
| 12 | 2607329115 | Suppression Capacitor |
| 13 | 1900905015 | Groove ball bearing 625-2Z DIN 625 |
| 14 | 1900905041 | Groove ball bearing 8X22X7 |
| 16 | 2604330016 | Brush Holder |
| 18 | 2603410001 | Socket head cap screw M3X6,5-4.8 |
| 19 | 2603490022 | Screw 4X16 |
| 2 | 2604220427 | Field 100V |
| 2 | 2604220441 | Field 240V |
| 2 | 2604220443 | Field 110-120V |
| 2 | 2604220445 | Field 220-230V |
| 25 | 2605500106 | Housing Cover Blue |
| 28 | 2608000126 | Closing Plate |
| 29 | 2605702005 | Flanged Fitting |
| 3 | 2604010909 | Armature 100V |
| 3 | 2604010910 | Armature 110-120V |
| 3 | 2604010911 | Armature 220-230V |
| 3 | 2604010912 | Armature 240V |
| 3/10 | 2606610027 | Fan |
| 30 | 2601005015 | Felt Strip |
| 32 | 2600905024 | Groove ball bearing 12X28X8 |
| 33 | 2600917003 | Needle-Roller Bearing Ø8X8 MM |
| 34 | 2606625006 | Toothed Belt Wheel Z=68 |
| 35 | 2606625005 | Toothed Belt Wheel Z=28 |
| 36 | 2606110000 | Eccentric Shaft |
| 37 | 2600232000 | Bearing Sleeve |
| 38 | 2605510014 | Air-Deflector Ring |
| 39 | 2600101014 | Shim washer |
| 4 | 2607200260 | Switch |
| 40 | 1600114038 | Conical Spring Washer |
| 42 | 2604736003 | Toothed Belt Z= 84 |
| 43 | 2600306003 | Seal Ring |
| 45 | 2602329022 | Pressure Bar |
| 47 | 2602098011 | Control Lever |
| 48 | 2600591004 | Plug |
| 49 | 2601330002 | Angle Piece |
| 5 | 1604460427 | Power supply cord CH 2,65M 2 X 1,0MM H05 Vv-F |
| 5 | 1614460010 | Power supply cord Usa/can/sma 2,15M 2 X 0,82MM SJ 16/2 |
| 5 | 2604460074 | Power supply cord AUS 2,6M 2 X 0,75MM Pvc |
| 5 | 2604460097 | Elec. Cable W/Connection |
| 5 | 2604460168 | Power supply cord GB 230V 2,65M 2 X 1,0MM H05 Vv-F |
| 5 | 2604460187 | Power supply cord Usa/cdn 2,68M 2 X 082MM SJ 18/2 |
| 5 | 2604460205 | Power supply cord GB 110V 2,65M 2 X 1,0MM H05 Vv-F |
| 5 | 2604460277 | Power supply cord I/br 2,65M 2 X 1,0MM H05 Vv-F |
| 5 | 3607030489 | Power supply cord |
| 50 | 2600108004 | Felt Washer |
| 51 | 2601316001 | Hose Clamp |
| 53 | 1604652004 | Spiral Spring |
| 54 | 2604681001 | Split Pin |
| 55 | 2604448071 | Cable White L=88MM |
| 55 | 2604465029 | Suppressor Box |
| 56 | 2604465033 | Suppressor Box |
| 57 | 2604448011 | Elec. Cable W/Connection White L = 194 MM |
| 58 | 2604448000 | Connecting Cable White L=154 MM |
| 59 | 2601022000 | Damping Plate |
| 6 | 2600703007 | Grommet Ø7 MM |
| 6 | 2600703008 | Grommet Ø8,2 MM |
| 61 | 2916660011 | Spring retaining ring DIN 472-28X1,2 MM |
| 62 | 1900210012 | O-Ring 15X2 MM |
| 63 | 2603490020 | Torx Oval-Head Screw 4X8 |
| 64 | 2603490003 | Thread-forming tap. Screw DIN 7500 C M 3X8 MM |
| 65 | 2603450008 | Thread-forming tap. Screw |
| 67 | 2914501028 | Screw and washer assembly M 4X12 MM |
| 69 | 2910861118 | Countersunk-Head Screw |
| 7 | 1611035005 | Cable Clip |
| 7 | 2601035001 | Cable Clip |
| 70 | 2910021138 | Socket head cap screw DIN 84-BM4X40-8.8 |
| 71 | 2916201002 | Plain Washer DIN 7349-4,3-ST |
| 76 | 2603490017 | Torx Oval-Head Screw 3X10 |
| 77 | 2601314002 | Support clamp |
| 774 | 2605411900 | Dust Bag |
| 78 | 2910011128 | Socket head cap screw DIN 84-AM4X18-5.8 |
| 79 | 2605500107 | Handle Cover |
| 801 | 2605104894 | Housing Section Blue |
| 81 | 2915011005 | Hex Nut DIN 934 -M4-M-8 |
| 810 | 2604321904 | Carbon-Brush Set |
| 82 | 2604448003 | Cable |
| 826 | 2608000900 | Pivot Plate |
| 827 | 2608000903 | Swing-Plate |
| 83 | 2604448049 | Connecting Cable White L=136MM |
| 831 | 1605133036 | Handle Black |
| 835 | 1607000227 | Power supply cord EU 4,15M 2 X 1,0MM H07 Rn-F |
| 888 | 160111A3H3 | Nameplate |
| 9 | 2601118586 | Manufacturer's nameplate |
| 9 | 3601119137 | Warning Plate Caution |
| 90 | 2606610026 | Fan |
