Bosch GML 20

Bosch GML 20 radio box: exploded parts diagram, 2 sheets, 40 positions. Spare parts with part numbers, availability and prices.

—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch GML 20: 40 positions on 2 sheets

Bosch GML 20 parts list (2 sheets)

Bosch GML 20 parts diagram, sheet 1Bosch GML 20 parts diagram, sheet 2
No.Part numberPart name
12610008308Aluminum Tubing
102610008315Fuse Holder
112610008316Radio Antenna
122610008317Damping rubber
132610008321Rubber Plug
142610008322Rubber Plug
152610008323Rubber Plug
162610008324Rubber Plug
172610008344Door Seal
172610008345Door Seal
182610008347Door Seal
182610008348Door Seal
192610008327Rotary Knob
22610008309Aluminum Tubing
212610008328Rotary Knob
222610008329Cover Flap
232610008330Holder
242610008331Corner Protection
252610008332Corner Protection
262610008333Corner Protection
272610008334Corner Protection
282610008335Corner Protection
292610008336Corner Protection
32610008310Aluminum Tubing
302610008337Corner Protection
312610008338Corner Protection
322610008339Cable Holder
332610012187Holding Handle
342610008350Housing Base
342610008351Housing Base
342610008355Housing Base
342610008356Housing Base
352610008361Damping rubber
362610008362Damping rubber
372610008363Damping rubber
42610008311Aluminum Tubing
52610008312Protective Grille
62610008313Cover Flap
6552610925218Antenna
72610008314Cover Flap
