Bosch GLI PortaLED
Bosch GLI PortaLED lamp box: exploded parts diagram, 1 sheet, 8 positions. Spare parts with part numbers, availability and prices.
—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch GLI PortaLED: 8 positions on 1 sheet
Bosch GLI PortaLED parts list (1 sheet)
| No. | Part number | Part name |
|---|---|---|
| 1 | 1600A000JT | Carrying Handle |
| 12 | 1600A000W4 | Electronic Module |
| 2 | 1600A000JU | Handle |
| 3 | 1600A000J5 | Seal Parts Set |
| 4 | 1600A000J7 | Coupling element |
| 5 | 1600A000J6 | Handle Plate |
| 6 | 1600A000W6 | Seal |
| 7 | 1600A000W5 | Inspection Glass |
