Bosch GDR 100
Bosch GDR 100 cordless percus screwdriv: exploded parts diagram, 1 sheet, 91 positions. Spare parts with part numbers, availability and prices.
—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch GDR 100: 91 positions on 1 sheet
Bosch GDR 100 parts list (1 sheet)
| No. | Part number | Part name |
|---|---|---|
| 1 | 2605104469 | Housing Section Blue |
| 1 | 2605104469 | Housing Section Blue |
| 100 | 2601322016 | Clamp Spring |
| 100 | 2601322016 | Clamp Spring |
| 102 | 2601329041 | Retaining Bracket |
| 102 | 2601329041 | Retaining Bracket |
| 110 | 2603490018 | Torx Oval-Head Screw 3X18 |
| 110 | 2603490018 | Torx Oval-Head Screw 3X18 |
| 113 | 2600100062 | Rubber Disc |
| 113 | 2600100098 | Rubber Disc |
| 114 | 2608040131 | Support |
| 114 | 2608040131 | Support |
| 115 | 2912341120 | Dummy DIN 965-M4X10-8.8-Z |
| 115 | 2912341120 | Dummy DIN 965-M4X10-8.8-Z |
| 116 | 2916640003 | Spring retaining ring DIN 471-6X0,7-FST |
| 116 | 2916640003 | Spring retaining ring DIN 471-6X0,7-FST |
| 118 | 2605510146 | Location Piece |
| 118 | 2605510146 | Location Piece |
| 119 | 2601310009 | Suspension Loop |
| 119 | 2601310009 | Suspension Loop |
| 120 | 2603100056 | Damping rubber |
| 120 | 2603100056 | Damping rubber |
| 20 | 2601118968 | Reference Plate Shadow Side |
| 20 | 2601118966 | Reference Plate Shadow Side |
| 27 | 1900900224 | Groove ball bearing 7X22X7 |
| 27 | 1900900224 | Groove ball bearing 7X22X7 |
| 29 | 2605510143 | Insert Piece Black |
| 29 | 2605510143 | Insert Piece Black |
| 38 | 2603000016 | Jack Shaft |
| 38 | 2603000016 | Jack Shaft |
| 40 | 2606309045 | Pinion Shaft Z= 10 |
| 40 | 2606309045 | Pinion Shaft Z= 10 |
| 41 | 2606319086 | Cylindrical Gear Z=23 |
| 41 | 2606319086 | Cylindrical Gear Z=23 |
| 56 | 1903230010 | Ball DIN 5401-5,5MM-III-ST |
| 56 | 1903230010 | Ball DIN 5401-5,5MM-III-ST |
| 57 | 2605700240 | Intermediate Flange |
| 57 | 2605700240 | Intermediate Flange |
| 58 | 2604610050 | Compression Spring |
| 58 | 2604610050 | Compression Spring |
| 67 | 2606445011 | Coupling Half |
| 67 | 2606445010 | Coupling Half |
| 67 | 2606445013 | Coupling Half |
| 70 | 2606319102 | Ring Gear |
| 70 | 2606319102 | Ring Gear |
| 72 | 2600322051 | Striker |
| 72 | 2600322051 | Striker |
| 753 | 2607224701 | Fast Charger EU 230/7,2-14,4V, 30 Min. |
| 753 | 2607224703 | Fast Charger GB 230/7,2-14,4V, 30 Min. |
| 753 | 2607224705 | Fast Charger AUS 240/7,2-14,4V, 30 Min. |
| 753 | 2607224708 | Fast Charger USA 120/7,2-14,4V, 30 Min. |
| 753 | 2607224711 | Fast Charger J 100/7,2-14,4V, 30 Min. |
| 753 | 2607224701 | Fast Charger EU 230/7,2-14,4V, 30 Min. |
| 753 | 2607224703 | Fast Charger GB 230/7,2-14,4V, 30 Min. |
| 753 | 2607224705 | Fast Charger AUS 240/7,2-14,4V, 30 Min. |
| 753 | 2607224708 | Fast Charger USA 120/7,2-14,4V, 30 Min. |
| 753 | 2607224711 | Fast Charger J 100/7,2-14,4V, 30 Min. |
| 754 | 2601398009 | Carrying Loop |
| 754 | 2601398009 | Carrying Loop |
| 79 | 2605806418 | Gear Housing |
| 79 | 2605806412 | Gear Housing Silver |
| 791 | 2607335039 | Slide-In Accu Package 12V, 1,7AH, Nicd |
| 791 | 2607335148 | Slide-In Accu Package 12V,2,0AH,NICD |
| 791 | 2607335039 | Slide-In Accu Package 12V, 1,7AH, Nicd |
| 791 | 2607335148 | Slide-In Accu Package 12V,2,0AH,NICD |
| 80 | 2605801023 | Plain bearing |
| 80 | 2605801018 | Plain bearing |
| 802 | 2607022955 | DC motor 12V |
| 802 | 2607022955 | DC motor 12V |
| 802/010 | 2606316147 | Pinion Z=13 |
| 802/010 | 2606316147 | Pinion Z=13 |
| 804 | 2607200353 | On-Off Switch |
| 804 | 2607200353 | On-Off Switch |
| 81 | 2601015063 | Radial Seal |
| 81 | 2601015062 | Radial Seal |
| 82 | 2916070006 | Serrated Lock-Washer A 4,3 DIN 6798-ST |
| 82 | 2916070006 | Serrated Lock-Washer A 4,3 DIN 6798-ST |
| 862 | 2600923006 | Ball Cage |
| 862 | 2600923006 | Ball Cage |
| 87 | 2601099055 | Adjusting Slide Red |
| 87 | 2601099055 | Adjusting Slide Red |
| 89 | 2605801019 | Plain bearing |
| 89 | 2605801019 | Plain bearing |
| 9 | 2601118967 | Manufacturer's nameplate Sunny Side |
| 9 | 2601119466 | Manufacturer's nameplate Sunny Side |
| 9 | 2601118965 | Manufacturer's nameplate Sunny Side |
| 9 | 2601119467 | Manufacturer's nameplate Sunny Side |
| 90 | 2600100639 | Plain Washer |
| 90 | 2600100638 | Plain Washer |
| 93 | 2608521018 | Screwdriver Blade |
| 93 | 2607000442 | Screwdriver Blade |
