Bosch GBM 13 RE drill: exploded parts diagram, 1 sheet, 56 positions. Spare parts with part numbers, availability and prices.
—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch GBM 13 RE: 56 positions on 1 sheet
Bosch GBM 13 RE parts list (1 sheet)
| No. | Part number | Part name |
|---|---|---|
| 13 | F000615056 | Dummy |
| 14 | 1610905005 | Groove ball bearing 9X24X7 |
| 2 | F000607087 | Dummy 127V |
| 2 | F000607088 | Field 220V |
| 20 | F00062100H | Reference Plate |
| 24 | F000619076 | Spindle |
| 27 | 1900905163 | Groove ball bearing 17X35X10 |
| 28 | 2600100695 | Shim 0,5 MM |
| 29 | 2916650008 | Spring retaining ring DIN 471 17X1 MM |
| 3 | F000605130 | Dummy 127V |
| 3 | F000605131 | Armature 220V |
| 32 | 2600101056 | Shim |
| 33 | 2606317084 | Cylindrical Gear |
| 35 | 2600101047 | Shim 0,3 MM |
| 37 | F000614005 | Catch Disk |
| 38 | 2600000021 | Shim washer 1,0 MM |
| 38 | 2600000030 | Shim washer 1,35 MM |
| 38 | 2600000031 | Shim washer 1,7 MM |
| 40 | 1903230009 | Ball DIN 5401-5 G28 |
| 42 | 2603120064 | Control Shaft |
| 44 | 2601015091 | Seal |
| 45 | 2600148008 | Air Guide Plate |
| 46 | F000616052 | Cross Recessed-Head Screw |
| 47 | 2605132055 | Housing Cover Dark Blue |
| 48 | 2601324048 | Contact Spring |
| 53 | 2600550008 | Disc Spring |
| 59 | F000617041 | Transmission |
| 61 | 2600100607 | Shim 0,3 MM |
| 62 | 2600914010 | Needle-Roller Bearing Ø6 MM |
| 63 | 2603435084 | Headless Screw |
| 64 | 2603435085 | Headless Screw |
| 69 | F000603152 | Cover |
| 72 | 9618087100 | Tapping Screw 4X20 MM |
| 73 | 9618087100 | Tapping Screw 4X20 MM |
| 74 | 1611329024 | Switch Contact |
| 75 | 1614465012 | Adapter module |
| 76 | 1614336086 | Brush Plate |
| 78 | 2916660014 | Spring retaining ring DIN 472 35X1,5 MM |
| 801 | F000601319 | Motor Housing |
| 804 | 2607200590 | On-Off Switch |
| 805 | F000609274 | Power supply cord BR 2,00M 2 X 1,00MM H05 Vvf |
| 805 | F000609280 | Power supply cord SAM 2,00M 2 X 1,00MM H05 Vvf |
| 805 | F000609285 | Power supply cord RCH 2,00M 2 X 1,00MM H05 Vvf |
| 806 | 2600707072 | Grommet |
| 810 | 1617000525 | Carbon-Brush Set 220 V / 127 V |
| 819 | 2603490017 | Torx Oval-Head Screw 3X10 |
| 825 | F000602018 | Transmission Case |
| 825 | F000602019 | Transmission Case |
| 843 | 2605700943 | Bearing Bracket |
| 85 | F000632031 | Chuck |
| 86 | F000610041 | Connecting Cable |
| 87 | F000610042 | Connecting Cable |
| 87 | F000610043 | Connecting Cable |
| 888 | 2601328900 | Holding Plate Black |
| 89 | F000603151 | Cover |
| 9 | F00062100G | Reference Plate |
