Bosch GAS 35 L SFC
Bosch GAS 35 L SFC all purpose vacuum cleane: exploded parts diagram, 6 sheets, 89 positions. Spare parts with part numbers, availability and prices.
—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch GAS 35 L SFC: 89 positions on 6 sheets
Bosch GAS 35 L SFC parts list (6 sheets)
| No. | Part number | Part name |
|---|---|---|
| 100 | 2609200392 | O-Ring |
| 101 | 2609200482 | O-Ring |
| 105 | 2609200450 | Caster Wheel |
| 106 | 2609200451 | Caster Wheel |
| 113 | 2609200406 | Plug |
| 124 | 2609200569 | Ferrite Core |
| 125 | 2609200479 | Switch |
| 15 | 2609200487 | Housing |
| 154 | 1600A01N6T | Mains Cable Aus |
| 154 | 1619PB6629 | Power Cable Ind |
| 154 | 2609200429 | Mains Cable EU |
| 154 | 2609200507 | Mains Cable Ch |
| 154 | 2609200517 | Mains Cable Gb |
| 190 | 2607432025 | Filter |
| 199 | 2609200422 | Screw |
| 201 | 2609200410 | Screw |
| 206 | 2609200414 | Positioning Element |
| 208 | 2609200481 | Fastening Part |
| 215 | 2609200397 | Lens Head Screw |
| 23 | 2609200453 | Support |
| 24 | 2609200425 | Locking Piece |
| 25 | 2609200452 | Support |
| 250 | 2609200454 | Clamping Ring |
| 251 | 2609200497 | Suction Pipe |
| 253 | 2608000A15 | Suction Pipe |
| 255 | 2609200455 | Nozzle |
| 259 | 2609200462 | Nozzle |
| 260 | 2609200496 | Socket |
| 28 | 2609200423 | Clamping Piece |
| 29 | 2609200390 | Support |
| 307 | 1619PB6632 | Sticker 1800W |
| 307 | 2609200447 | Sticker 2200W |
| 307 | 2609200506 | Sticker 1200W |
| 307 | 2609200512 | Sticker 1800W |
| 308 | 2609200438 | Screw |
| 313 | 2609200486 | Electrical accessories |
| 320 | 2609200456 | Bolt |
| 322 | 2609200461 | Fastening Part |
| 37 | 2609200427 | Sensor |
| 414 | 2609200441 | Sticker |
| 418 | 2609200490 | Plate |
| 419 | 2609200498 | Warning Plate |
| 420 | 2609200478 | Manufacturer's nameplate GAS 35 L Sfc |
| 47 | 2609200483 | Spring |
| 72 | 2609200420 | Seal |
| 80 | 2609200489 | Motor Housing |
| 8020 | 1607000D8X | Support |
| 8021 | 2609200388 | Switch |
| 8031 | 2609200493 | Housing |
| 8032 | 2609200477 | Cover |
| 8033 | 2609200391 | Cover |
| 8034 | 2609200430 | Hood |
| 8035 | 2609200488 | Container |
| 8036 | 2609200458 | Axle |
| 8039 | 2609200444 | Handle |
| 8049 | 1600A01N6Y | Marking Plate GAS 35 L Sfc+ Made In Italy |
| 8049 | 1619PB6631 | Nameplate GAS 35 L Sfc+ Made In Italy |
| 8049 | 2609200485 | Nameplate GAS 35 L Sfc Made In Italy |
| 8049 | 2609200503 | Nameplate Made In Italy |
| 8049 | 2609200508 | Nameplate GAS 35 L Sfc Made In Italy |
| 8049 | 2609200519 | Nameplate GAS 35 L Sfc Made In Italy |
| 8050 | 160111AA28 | Nameplate Made In Romania |
| 8050 | 160111AA29 | Nameplate Made In Romania |
| 8050 | 160111AA2A | Nameplate Made In Romania |
| 8050 | 160111AA2B | Nameplate Made In Romania |
| 8050 | 160111AA2C | Nameplate Made In Romania |
| 8058 | 2609200449 | Bumper |
| 8068 | 2609200431 | Seal Kit |
| 8075 | 2609200480 | Valve Plate |
| 8090 | 2609200413 | Sound Insulation Mat |
| 8092 | 2609200437 | Sound Insulation Mat |
| 8103 | 2609200432 | Wheel |
| 8107 | 2609200415 | Motor |
| 8110 | 2609200435 | Holder |
| 8111 | 2609200407 | Holder |
| 8113 | 2609200405 | Fastening parts kit |
| 8115 | 2609200393 | Filter Cover |
| 8161 | 2609200412 | Cable |
| 8162 | 2609200570 | Cable |
| 8175 | 2609200386 | Wafer |
| 8257 | 2608000A09 | Hose |
| 8301 | 2609200484 | Operator Panel |
| 8303 | 2609200446 | Socket |
| 8303 | 2609200501 | Socket |
| 8303 | 2609200505 | Socket |
| 8303 | 2609200516 | Socket |
| 8321 | 2609200428 | Spring Housing |
| 85 | 2609200436 | Hose Holder |
| 99 | 2609200424 | Cord |
