Bosch DIY HAMMER DRILL jig saw: exploded parts diagram, 1 sheet, 100 positions. Spare parts with part numbers, availability and prices.

—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Bosch DIY HAMMER DRILL: 100 positions on 1 sheet

Bosch DIY HAMMER DRILL parts list (1 sheet)

Bosch DIY HAMMER DRILL parts diagram, sheet 1
No.Part numberPart name
122607329138Suppression Capacitor
142600905021Groove ball bearing 9X24X7
162605807060Brush Plate
162605807122Brush Plate
162609992617Brush Plate
182603410001Socket head cap screw M3X6,5-4.8
22604220447Field 230-240V
22604220482Field 100-115V
2071611035005Cable Clip
2072601035001Cable Clip
2192910611019Tapping Screw DIN 7981-ST3,9X16-C-H
272600101047Shim 0,3 MM
282600101048Shim 0,5 MM
292600102614Shim 0,5 MM
32604010893Armature 100V
32604010894Armature 115V
32604010895Armature 230V
3/602606610050Fan
302601098025Counterweight 5,5 MM
312601923009Fork Lever
322600913007Needle-Roller Assembly
332606320049Eccentric Cog Wheel Z=39
352600200035Intermediate Ring
382600780060Lifting Rod
392600302009Sintered-Metal Bushing
42607200303On-Off Switch
42607200312On-Off Switch
402600101612Shim 0,5 MM
402600116012Shim 0,3 MM
412602316011Support Plate
422601322014Guide Bracket
432604613000Compression Spring
442910950128Oval-Head Screw DIN 7985-M4X18-8.8-H
452603490004Clamp Screw
462606491012Coupling Half
472606491010Ratchet
482600451002Guide Sleeve
492608040073Rotary Handle
51604460015Power supply cord CH 4,15M 2 X 1,0MM H05 Vv-F
51614460010Power supply cord Usa/can/sma 2,15M 2 X 0,82MM SJ 16/2
52604460095Power supply cord J 2,5M 2 X 0,75MM Pvc
52604460131Power supply cord I 4,15M 2 X 1,0MM H05 Vv-F
52604460132Power supply cord GB 4,15M 2 X 1,00MM H05 Vv-F
52604460290Power supply cord AUS 240V 2,6M 2 X 0,75MM H05 Vv-F
502601321049Roller Lever
512601015057Sealing Plate
522609002725Straight Pin
532917530099Straight Pin DIN 6325-4M6X20
542600100510Shim 0,5 MM
552602026055Change-Over Switch Black 230V
562600590006Ratchet Cap
572600100568Shim 0,5 MM
572600100572Shim
572600100607Shim 0,3 MM
592600400030Retaining snap ring
62600703006Grommet Ø9,5 MM
62600703007Grommet Ø7 MM
62600703008Grommet Ø8,2 MM
612600210036O-Ring 5,0X1,75 MM
622603201020Bearing bolt
632608040074Rotary Handle
642606491013Ratchet
652606333029Pinion Z=8
662606333028Bevel Gear Z=32
672602317028Profile Beading
682601016073Base Plate
692605730037Suction Channel
702605510149Covering hood
712608040075Inserted Part
722608040077Sealing cap
732601329047Contact Spring
752603100055Loop
7532600499032Fitting
762604448190Connecting Cable White L=50 MM
772604448123Connecting Cable White L=73 MM
802607230024Speed governor 230-240V
802607230028Speed governor 100V
802607230029Speed governor 120V
8012605104854Housing Section Green
801/032600506008Press-In Socket
8051607000389Power supply cord
8082601119260Marking Plate
8082601119261Marking Plate
8082601119262Nameplate
8082601119264Marking Plate
8082601119265Marking Plate
8082601119266Marking Plate
8082601119457Marking Plate
812604610040Compression Spring
8132600917901Needle bearing
816/042604321905Carbon-Brush Set
816/042604321916Carbon-Brush Set
816/062601322013Ratchet Cap
816/062601329051Ratchet Cap
8252605807925Bearing Bracket
8342916080909Locking washer DIN 6799-6-FST
8362600917900Needle bearing
8582916080008Locking washer DIN 6799-5-FST
8742910611020Tapping Screw DIN 7981-ST3,9X19-C-H
92601118352Manufacturer's nameplate Sunny Side
