Makita DBM131
Makita DBM131: exploded parts diagram, 1 sheet, 58 positions. Spare parts with part numbers, availability and prices.
—
Scroll to zoom · drag to move
All parts on this sheet0
All parts of Makita DBM131: 58 positions on 1 sheet
Sheet 1: Makita DBM131 parts diagram
| No. | Part number | Part name |
|---|---|---|
| 2 | EE73320150 | |
| 3 | EE80900159 | |
| 4 | EE80900072 | |
| 5 | EE80900073 | |
| 6 | EE80201199 | |
| 7 | EE80700019 | |
| 10 | EE80201252 | Makita EE80201252 TAPPING SCREW 2,9X13 UT120X |
| 11 | EE80201131 | |
| 12 | EE73421261 | |
| 13 | EE80200752 | |
| 14 | EE80201295 | |
| 15 | EE80601148 | |
| 16 | EE80201273 | |
| 17 | EE80201362 | |
| 20 | EE80600306 | Makita EE80600306 SPONGE SHEETUT121 |
| 21 | EE80201267 | Makita EE80201267 TAPPING SCREW 4,8X45 UT120X |
| 22 | EE73320305 | |
| 23 | EE80201371 | |
| 24 | EE80600116 | |
| 25 | EE73119262 | |
| 26 | EE83000004 | Makita EE83000004 CABLE BUSHINGUT121 |
| 27 | EE85000020 | Makita EE85000020 CLIPUT121 |
| 28 | EE80201270 | Makita EE80201270 TAPPING SCREW 4,2X13 UT120X |
| 29 | EE80201272 | |
| 31 | EE7332S610 | |
| 32 | EE82000501 | Makita EE82000501 GASKET |
| 33 | EE83000019 | |
| 34 | EE80900120 | |
| 37 | EE80201275 | |
| 38 | EE80200580 | |
| 39 | EE73429400 | |
| 41 | EE80601153 | |
| 43 | EE83000106 | |
| 44 | EE80410152 | |
| 45 | EE80410051 | |
| 46 | EE80201121 | |
| 47 | EE80201302 | |
| 51 | EE7342749K | |
| 58 | EE73421440 | |
| 59 | EE80201319 | |
| 60 | EE73427420 | |
| 62 | EE80430029 | |
| 64 | EE83000022 | |
| 65 | EE83000017 | |
| 66 | EE73320542 | |
| 67 | EE80201149 | |
| 68 | EE80900074 | |
| 69 | EE83000031 | |
| 71 | EE7DE33695 | |
| 72 | EE83000124 | |
| 73 | EE83000109 | |
| 74 | EE83000107 | |
| 75 | EE83000100 | |
| 77 | EE73427405 | |
| 78 | EE80200745 | |
| 79 | EE83000070 | |
| 80 | EE80201339 | |
| 81 | EE80200582 | Makita EE80200582 PIN 4 UT120X |
